HPE P57774-B21 | ProLiant DL380 Gen10 8SFF SAS/SATA Backplane, Box 1-2
SKU:P57774-B21
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This backplane kit adds eight small-form-factor drive bays to the HPE ProLiant DL380 Gen10 2U rack server. It suits storage-dense deployments where the server needs to host eight hot-plug SAS/SATA drives in the drive box 1-2 position.
The kit provides eight SFF (2.5-inch) bays on a basic carrier (BC) drive cage with a SAS/SATA interface. It includes a 12G SAS UBM6 backplane PCA and is powered from the host server. The SKU is defined by its 8SFF SAS/SATA configuration, Basic Carrier design and Box 1-2 position, which separates it from other DL380 Gen10 drive cage options.
It is designed for the DL380 Gen10 and works with the HPE Tri-Mode storage controller for SAS/SATA drives. It requires the HPE ProLiant DL38x 8SFF SAS/SATA Tri-Mode Cable Kit (P55467-B21). Selecting two of these 8SFF drive cages rules out the graphics option.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Adds 8 SFF SAS/SATA drive capacity to the DL380 Gen10
- Basic Carrier (BC) drive cage design
- Fits the drive box 1-2 position
- Includes a 12G SAS UBM6 backplane PCA
- Supports the HPE Tri-Mode storage controller for SAS/SATA drives
- Powered from the host DL380 Gen10 server
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product type: Backplane (drive cage kit)
- Drive bays: 8 x SFF (2.5-inch)
- Interface: SAS/SATA
- Carrier type: Basic Carrier (BC)
- Drive box position: Box 1-2
- Compatible server: HPE ProLiant DL380 Gen10
- Backplane PCA: 12G SAS UBM6
- Manufacturer part number: P57774-B21
FAQs
Q: Which server is this backplane for?
A: It is for the HPE ProLiant DL380 Gen10 2U rack server, in the drive box 1-2 position.
Q: Does it need a separate cable kit?
A: Yes. It requires the HPE ProLiant DL38x 8SFF SAS/SATA Tri-Mode Cable Kit (P55467-B21).
Q: Can I fit two of these drive cages?
A: You can select two of these 8SFF drive cages (P57774-B21), but doing so rules out the graphics option.
Q: Which drive types does it support?
A: It provides eight SFF (2.5-inch) bays with a SAS/SATA interface.
Q: Are there any operating system limits?
A: Broadcom MegaRAID controllers are not supported with Windows Server 2012 R2 on Gen10 servers.
