HPE

HPE P57129-B21 | DL345 Gen11 24SFF backplane | Tri-Mode PCIe x2 | Boxes 1–3 | SAS/SATA/NVMe | Internal cabling kit

SKU:P57129-B21

Regular price POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

Tri-Mode internal PCIe cabling set for DL345 Gen11 24SFF chassis, sized for Boxes 1–3. Provides x2-lane connectivity from your supported Tri-Mode controller/HBA to the front SFF backplanes for SAS, SATA, or NVMe drives. Ideal when a dual-lane topology meets performance needs or controller ports. Ensures neat routing and stable signal quality in dense storage builds.

Features

- Tri-Mode support for SAS/SATA/NVMe with compatible hardware
- x2 PCIe lane topology for efficient port utilization
- Purpose-built lengths for DL345 Gen11 24SFF Boxes 1–3
- Clean cable management and reliable signal integrity
- Quick integration into existing Gen11 storage builds

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details
  • You may also like
  • Best sellers
  • Related Products

specs-tabs

Collapsible content

FAQs

Technical Specifications

FAQs

Q: How does the x2 kit differ from the x4 kit?
A: This kit uses a two-lane (x2) PCIe topology per connection rather than x4. Choose based on your controller port layout and performance requirements.

Q: Which drive types are supported?
A: The cabling supports SAS, SATA, and NVMe with the appropriate Tri-Mode controller and backplane.

Q: Is installation tool-free?
A: Installation is internal and typically does not require special tools, but standard ESD-safe service procedures should be followed.

Q: Does it include a controller?
A: No, the controller/HBA is not included.

Technical Specifications

- Product type: Tri-Mode PCIe internal cable kit
- Compatibility: ProLiant DL345 Gen11, 24SFF chassis
- Backplane coverage: Boxes 1–3 (front SFF bays)
- Lane configuration: x2 PCIe per assembly
- Protocol support: SAS / SATA / NVMe (Tri-Mode)
- Use case: Connect Tri-Mode RAID/HBA/PCIe storage controller to front backplanes
- Form factor: Server-internal cable harness set
- Notes: Requires compatible Gen11 Tri-Mode backplanes and controller
