HPE P57128-B21 | DL345 Gen11 24SFF backplane | Tri-Mode PCIe x4 | Boxes 1–3 | SAS/SATA/NVMe | Internal cabling kit

SKU:P57128-B21

Regular price POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

Tri-Mode internal PCIe cabling set for DL345 Gen11 24SFF chassis, sized for Boxes 1–3. Provides x4-lane connectivity from your supported Tri-Mode controller/HBA to the front SFF backplanes for SAS, SATA, or NVMe drives. Purpose-built lengths and terminations ensure clean routing and reliable signal integrity inside the server. Ideal for expanding high-performance, mixed-protocol storage configurations.

Features

- Tri-Mode ready: SAS, SATA, and NVMe support with compatible hardware
- Sized for DL345 Gen11 24SFF Boxes 1–3 for clean internal routing
- x4 PCIe lane configuration for high-performance storage paths
- Engineered for signal integrity and reliable throughput
- Simplifies field installation and serviceability

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details
  • You may also like
  • Best sellers
  • Related Products

specs-tabs

Collapsible content

FAQs

Technical Specifications

FAQs

Q: Does this kit include all cables needed for Boxes 1–3?
A: Yes, it is designed to provide the internal Tri-Mode x4 cabling required to link a supported controller to the 24SFF backplane Boxes 1–3.

Q: Which drive types are supported with this cabling?
A: Tri-Mode cabling supports SAS, SATA, and NVMe when used with compatible Gen11 backplanes and controllers.

Q: Can I mix SAS/SATA and NVMe drives on the same backplane?
A: Mixed-protocol operation depends on the specific backplane and controller configuration. Ensure your hardware explicitly supports mixed Tri-Mode operation.

Q: Is a storage controller included?
A: No, this listing is for the internal cable kit only. A compatible Tri-Mode controller/HBA is required.

Technical Specifications

- Product type: Tri-Mode PCIe internal cable kit
- Compatibility: ProLiant DL345 Gen11, 24SFF chassis
- Backplane coverage: Boxes 1–3 (front SFF bays)
- Lane configuration: x4 PCIe per assembly
- Protocol support: SAS / SATA / NVMe (Tri-Mode)
- Use case: Connect Tri-Mode RAID/HBA/PCIe storage controller to front backplanes
- Form factor: Server-internal cable harness set
- Notes: Requires compatible Gen11 Tri-Mode backplanes and controller
