HPE P57126-B21 | ProLiant DL345 Gen11 24SFF NVMe x2 Direct Attach Cable Kit
SKU:P57126-B21
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
Cable kit for the HPE ProLiant DL345 Gen11 2U server that connects three 8SFF x4 U.3 NVMe backplanes in drive boxes 1-3 directly to the system board at x2 bandwidth. It enables a 24 SFF NVMe direct attach configuration without a PCIe storage controller, suiting high-density flash storage deployments. This Box 1-3, x2 variant is distinct from the x4 direct attach and Tri-Mode controller kits available for the same chassis.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Direct attach NVMe with no PCIe storage controller required
- Connects three 8SFF x4 U.3 NVMe backplanes to the system board
- Selectable cable option when three P55083-B21 backplanes are chosen in the 24SFF CTO server
- Can also be used in a front and mid-tray 32SFF direct attach (NVMe x2) configuration
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Part number: P57126-B21
- Compatible chassis: HPE ProLiant DL345 Gen11, 2U, 24SFF
- Supports 24 SFF U.3 NVMe drives in Box 1-3 via direct attach
- Bandwidth: x2 PCIe per drive
- For use with three 8SFF x4 U.3 backplanes (P55083-B21)
- Approx. weight: 2.635 lb
FAQs
Q: Which server is the P57126-B21 cable kit designed for?
A: It is designed for the HPE ProLiant DL345 Gen11 2U server in the 24SFF configuration.
Q: Does this kit require a storage controller?
A: No. It provides a direct attach connection from the NVMe backplanes to the system board, so no PCIe storage controller is required.
Q: Which backplanes does this kit connect?
A: It connects three 8SFF x4 U.3 NVMe backplanes (P55083-B21) in drive boxes 1-3.
Q: What is the difference between this kit and the x4 direct attach kit?
A: This kit provides x2 PCIe bandwidth per drive. The x4 direct attach kit, P57125-B21, provides x4 bandwidth and requires two OCP retimers.
Q: Is there a controller-based alternative for the same chassis?
A: Yes. The x2 Tri-Mode controller kit, P57129-B21, is the controller-based option for the DL345 Gen11 24SFF chassis.
