HPE P55082-B21 | ProLiant DL385 Gen11 8SFF Tri-Mode U.3 x1 Backplane Kit
SKU:P55082-B21
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This 8SFF Tri-Mode U.3 backplane kit is a front-bay drive cage for the HPE ProLiant DL385 Gen11 server. It adds eight 2.5-inch Basic Carrier bays and suits buyers expanding front storage with SAS, SATA or NVMe U.3 drives, including mixed-media and cost-efficient NVMe deployments.
Each bay is provided with a single PCIe x1 link (x1 U.3), and the backplane supports SATA, SAS and NVMe U.3 in both static and dynamic modes. Up to three of these front cages can be configured per server. It can be mixed with x4 U.3 8SFF backplanes in the same server, although an x4 mid cage is not supported alongside the x1 version. The kit weighs approximately 1.4 kg.
The backplane is supported by both OROC (OCP Smart Array) and PCIe storage controllers. A controller-specific OROC x1 or PCIe x1 cable kit is required for controller connectivity, and the DL385 Gen11 SFF Backplane Power Cable Kit (P57845-B21) is ordered separately to supply power from the server PSU.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Tri-Mode U.3 support for SATA, SAS and NVMe drives in the same 8SFF cage
- x1 PCIe lane per bay for cost-efficient NVMe connectivity
- Basic Carrier (BC) drive cage design used across the DL385 Gen11
- Can be mixed with x4 U.3 8SFF backplanes in the same server
- Compatible with both OROC (OCP Smart Array) and PCIe storage controllers
- Up to three front cages configurable per server
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Manufacturer part number: P55082-B21
- Product type: Server backplane kit (drive cage)
- Form factor: SFF, 8 bays
- Drive carrier: Basic Carrier (BC)
- Backplane type: Tri-Mode U.3, front
- Supported drives: SATA, SAS, NVMe U.3 (static and dynamic)
- PCIe lanes: x1 per bay (x1 U.3)
- Compatible server: HPE ProLiant DL385 Gen11
- Max quantity per server: up to 3 front cages
- Weight: 1.4 kg (3.09 lb)
- Power cable: DL385 Gen11 SFF Backplane Power Cable Kit P57845-B21 (ordered separately)
- Controller support: OROC (OCP Smart Array) and PCIe storage controllers
FAQs
Q: Does this backplane need a separate power cable?
A: Yes. The HPE ProLiant DL385 Gen11 SFF Backplane Power Cable Kit (P57845-B21) is ordered separately. Power is then drawn from the server PSU.
Q: Which cables are needed to connect it to a storage controller?
A: A controller-specific cable kit is required, either an OROC x1 or a PCIe x1 cable kit, depending on whether you use an OCP Smart Array or a PCIe storage controller.
Q: What drive types does it support?
A: It supports SATA, SAS and NVMe U.3 drives, with NVMe U.3 in both static and dynamic modes.
Q: How does it differ from the x4 U.3 backplane kit?
A: This kit provides one PCIe lane (x1) per bay for cost-efficient NVMe, whereas the x4 U.3 kit provides four lanes per bay. The two can be mixed in the same server, but an x4 mid cage is not supported alongside the x1.
Q: How many of these can be installed in one server?
A: Up to three of these front drive cages can be configured in a DL385 Gen11.
