• Juniper Compatible 1GB BiDi SFP Transceiver with Purple Fiber Connector
1 1

Blue Cable Co

EX-SFP-GE10KT14R13-BCC | Juniper Compatible 1GB BiDi Transceiver - 10km (1000BASE-BX-D)

EX-SFP-GE10KT14R13-BCC

13 in stock

$55.99 inc. GST
$50.90 ex. GST
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The EX-SFP-GE10KT14R13-BCC is a drop-in compatible replacement for the Juniper EX-SFP-GE10KT14R13. This plug-and-play BiDi transceiver works in any Juniper platform with a Gigabit Ethernet SFP port requiring 1000BASE-BX10-D connectivity. - 1000BASE-BX10-D standard compliance ensures interoperability with Juniper equipment and complementary wavelength transceivers - SFP form factor, 1.25 Gbps data rate, transmits at 1490nm and receives at 1310nm over single-mode fibre to 10km - Bidirectional operation over a single fibre strand reduces fibre infrastructure requirements by 50 percent compared to duplex links - Must be deployed as a matched pair with EX-SFP-GE10KT13R14 (Tx 1310nm/Rx 1490nm) to establish a functional link - DOM support provides real-time monitoring of optical power, temperature, bias current, and supply voltage - Single LC simplex connector, operates over standard OS1 or OS2 single-mode fibre

Features

• IEEE 802.3ah 1000BASE-BX10 compliance guarantees compatibility with Juniper SFP ports and ensures proper link negotiation at 1.25 Gbps line rate
• Bidirectional wavelength pairing (Tx 1490nm / Rx 1310nm) enables simultaneous transmit and receive over a single fibre strand using WDM technology, classified as 1000BASE-BX10-D side
• Requires matched pair deployment with complementary 1000BASE-BX10-U transceiver (Tx 1310nm / Rx 1490nm) at the opposite end of the link for bidirectional communication
• MSA-compliant SFP footprint supports hot-swap installation without service interruption, with automatic link initialization upon insertion
• Digital diagnostics interface provides real-time access to five monitored parameters (TX power, RX power, temperature, bias current, voltage) via I2C for proactive link health management
• Designed for 10km transmission over ITU-T G.652 compliant single-mode fibre with sufficient link budget to accommodate typical installed cable plant attenuation and connector losses
• Commercial temperature rating (0°C to 70°C) suits deployment in controlled environment data centres, telco facilities, and enterprise network closets

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we’ll deliver a replacement part before you return the faulty item—minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

Also Known As

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: EX-SFP-GE10KT14R13-BCC
Compatible Replacement For: EX-SFP-GE10KT14R13
Compatibility: Juniper compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: SFP
Data Rate: 1.25 Gbps
Standard: 1000BASE-BX10-D
Wavelength: 1490nm TX / 1310nm RX
Fibre Type: Single-mode (SMF)
Connector Type: Single LC simplex
Max Reach: 10km (over OS1/OS2 single-mode fibre)
DOM Support: Yes
Operating Temperature: 0°C to 70°C (commercial)

Also Known As

740-020465, SFP-GE10KT14R13

FAQs

Q: Will this work in place of the Juniper EX-SFP-GE10KT14R13?
A: Yes. This transceiver is a direct replacement based on 1000BASE-BX10-D standard compliance, matching the SFP form factor, 1.25 Gbps data rate, and 1490nm TX / 1310nm RX wavelength specification. It is plug-and-play in any Juniper equipment that lists the EX-SFP-GE10KT14R13 as a supported transceiver.

Q: Which Juniper platforms support this transceiver?
A: This module is compatible with Juniper switches, routers, and security appliances that feature Gigabit Ethernet SFP ports and support 1000BASE-BX10 operation. This includes platforms across the EX, MX, SRX, QFX, and ACX families. Confirm compatibility by verifying your platform supports the EX-SFP-GE10KT14R13 in Juniper's Hardware Compatibility Tool.

Q: Why must this transceiver be paired with a specific complementary module?
A: BiDi transceivers use wavelength division multiplexing (WDM) to achieve bidirectional communication over a single fibre. This module transmits at 1490nm and receives at 1310nm (the -D or downlink side). The opposite end must use a transceiver that transmits at 1310nm and receives at 1490nm (the -U or uplink side, such as EX-SFP-GE10KT13R14). Mismatched wavelengths prevent link establishment.

Q: What is the actual reach over installed single-mode fibre?
A: The 10km specification assumes standard OS1 or OS2 single-mode fibre with typical attenuation of 0.35 to 0.5 dB/km at 1310nm and 1490nm, plus connector and splice losses. The module provides sufficient link budget (typically 15 to 18 dB) to support 10km under normal conditions. Actual reach depends on total path loss, which should be verified with an optical power meter or calculated from fibre plant records.

Q: Can this transceiver operate in CWDM or DWDM systems?
A: No. This is a fixed-wavelength BiDi transceiver designed for point-to-point links between matched pairs. It is not a tunable or CWDM/DWDM-compatible module. The 1490nm and 1310nm wavelengths fall outside standard CWDM ITU grid channels. For wavelength multiplexing applications, use dedicated CWDM or DWDM transceivers with the appropriate channel spacing and multiplexer equipment.

Compatible SFP Selector

Need a Compatible SFP or QSFP Transceiver?

Use the Blue Cable Co Compatible SFP Selector to quickly filter by vendor compatibility, speed, form factor, fibre type, distance and connector and only see options that exist in our range.
Fully tested. No brand-tax. Sydney re-coding available if required.

Find Compatible Transceivers

100% compatible with equipment from major vendors

Coded and tested in our state of the art lab in Sydney

Cisco sfp-10g-sr transceiver module with metallic housing and a white label displaying serial number, model details, and regulatory markings.
Silver-colored sfp-10g-sr-bcc transceiver module with a white label featuring blue and black text, designed for 850nm wavelength optical communication.
Blue Cable Co
Cisco

Tested on real vendor hardware in Sydney

Every Blue Cable Co transceiver is coded for your platform and tested in our Sydney test rack on real vendor switches and firewalls before it ships. We check it is recognised and links up the same way the OEM optic does, so you don't find an "unsupported transceiver" error after it's installed.

Brands tested: Cisco, Meraki, Arista, Aruba, HPE, Juniper, Dell, Fortinet, Palo Alto, Check Point, Sophos, Moxa and NVIDIA. Speeds up to 100Gb.

  • 5 year replacement warranty
  • Sydney stock
  • Re-coding if you need it
