Cisco UCSX-MRX16G1RE1 | UCS X-Series M7 16GB DDR5-4800 1Rx8 RDIMM Memory

SKU:UCSX-MRX16G1RE1

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This 16GB DDR5-4800 registered DIMM is memory for the Cisco UCS X-Series M7 range. It is a single rank x8 module built on 16Gb DRAM density, intended for main memory expansion or replacement in UCS X210c M7 and X410c M7 compute nodes. Typical uses are data centre, virtualisation and general enterprise workloads.

The module is a registered DDR5 DIMM with on-die ECC, in a 288-pin form factor and running at 1.1V. With 4th Gen Intel Xeon Scalable processors it runs at up to 4800 MT/s at one DIMM per channel and up to 4400 MT/s at two DIMMs per channel. Each CPU provides 8 memory channels with up to 2 DIMMs per channel, allowing up to 32 DIMMs in a 2-socket X210c M7 and up to 64 in a 4-socket X410c M7. This 1Rx8 part does not support SDDC or ADDDC.

DDR5-4800 and DDR5-5600 DIMMs cannot be mixed in a server with 4th Gen Intel Xeon CPUs, so plan the population accordingly. Refer to the Cisco UCS M7 memory guide for population rules.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Registered DDR5 DIMM with on-die ECC
- Low-voltage 1.1V operation
- Single rank x8 organisation on 16Gb DRAM
- Supported on UCS X210c M7 and X410c M7 compute nodes
- Designed for 4th Gen Intel Xeon Scalable processors
- Cisco-qualified memory for UCS M7 servers

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Capacity: 16GB
- Memory type: DDR5 RDIMM (registered, on-die ECC)
- Speed: DDR5-4800 MT/s
- Rank and organisation: 1Rx8 (single rank, x8)
- DRAM density: 16Gb
- Operating voltage: 1.1V
- Form factor: 288-pin DIMM
- Speed at 1 DIMM per channel: up to 4800 MT/s (4th Gen Intel Xeon)
- Speed at 2 DIMMs per channel: up to 4400 MT/s (4th Gen Intel Xeon)
- Memory channels: 8 per CPU, up to 2 DIMMs per channel
- Maximum DIMMs per server: 32 (2-socket X210c M7), 64 (4-socket X410c M7)
- RAS: SDDC and ADDDC not supported on this x8 DIMM
- Supported servers: Cisco UCS X210c M7, UCS X410c M7

FAQs

Q: Which servers is this memory for?
A: It is for Cisco UCS X210c M7 and X410c M7 compute nodes with 4th Gen Intel Xeon Scalable (Sapphire Rapids) processors.

Q: Can it be mixed with DDR5-5600 DIMMs?
A: No. DDR5-4800 and DDR5-5600 DIMMs cannot be mixed in a server with 4th Gen Intel Xeon CPUs, so keep all DIMMs in the server at the same speed grade.

Q: What speed will it run at?
A: With 4th Gen Intel Xeon processors it runs at up to 4800 MT/s with one DIMM per channel and up to 4400 MT/s with two DIMMs per channel.

Q: How many of these DIMMs can a server hold?
A: Each CPU has 8 memory channels with up to 2 DIMMs per channel. That allows up to 32 DIMMs in a 2-socket X210c M7 and up to 64 in a 4-socket X410c M7.

Q: Does it support SDDC or ADDDC?
A: No. SDDC and ADDDC are not supported on the 16GB 1Rx8 (x8) DIMM.
