Cisco

Cisco UCSX-GPU-H200-NVL | H200 NVL 141GB HBM3e GPU, 600W, 2-Slot NVL2 FHFL

UCSX-GPU-H200-NVL

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The NVIDIA H200 NVL is a Tensor Core GPU accelerator supplied by Cisco as an option for the UCS X580p PCIe Node in the Cisco UCS X-Series modular system. It is built for LLM inference and for generative AI training and fine-tuning, and suits organisations running enterprise AI workloads on-premises.

The card is a 2-slot, full-height, full-length NVL2 form factor, air-cooled PCIe Gen5 GPU with 141GB of HBM3e memory and a 600W power rating. NVLink Bridge support is available on the air-cooled design, so paired GPUs can be linked without a performance impact or power throttling per compute node. Up to four cards fit in a single UCS X580p PCIe Node, and up to eight GPUs can be deployed across a UCS X9508 chassis with two X580p nodes.

It installs in the UCS X580p PCIe Node (UCSX-580P-U), which requires UCS X9516 X-Fabric modules in a UCS X9508 chassis. It pairs with UCS X210c M8 and UCS X215c M8 compute nodes, and the host system is managed through Cisco Intersight in Intersight Managed Mode, with a minimum Essentials licence per server.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Supports high-performance LLM inference and generative AI training and fine-tuning
- Air-cooled GPUs with NVLink Bridge support, without performance impact or power throttling per compute node
- GPUs from a single X580p can be shared across up to two compute nodes
- Programmable PCIe fabric via UCS X9516 X-Fabric for flexible GPU provisioning from Cisco Intersight
- Policy-based GPU provisioning and unified monitoring of AI infrastructure through Cisco Intersight
- SmartNIC support for GPU-to-GPU communication over an AI fabric for scale-out
- Disaggregation of compute and GPU resources across the X-Series modular system

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- GPU: NVIDIA H200 NVL Tensor Core GPU
- GPU memory: 141GB HBM3e
- Power rating: 600W
- Host interface: PCIe Gen5 x16
- Form factor: 2-slot (dual-slot) full-height, full-length (FHFL), NVL2
- Cooling: Air-cooled with NVLink Bridge support
- Maximum GPUs per UCS X580p PCIe Node: Up to 4
- Maximum GPUs per UCS X9508 chassis: Up to 8 (with two X580p nodes)
- Host node compatibility: Cisco UCS X210c M8 (Intel Xeon 6) and UCS X215c M8 (AMD EPYC)
- Required X-Fabric: Cisco UCS X9516 X-Fabric modules
- Supported chassis: Cisco UCS X9508 Chassis
- Supported fabric interconnects: Cisco UCS 4th, 5th and 6th Generation Fabric Interconnects
- Management: Cisco Intersight, Intersight Managed Mode with minimum Essentials licence per server
- X580p node operating temperature: 10 to 27 C
- X580p node operating humidity: 5% to 93% non-condensing
- X580p node operating altitude: 0 to 3000 m

FAQs

Q: Which Cisco node does this GPU install in?
A: It installs in the Cisco UCS X580p PCIe Node (UCSX-580P-U), which requires UCS X9516 X-Fabric modules in a UCS X9508 chassis.

Q: Which compute nodes can it be paired with?
A: The X580p PCIe Node pairs with Cisco UCS X210c M8 (Intel Xeon 6) and UCS X215c M8 (AMD EPYC) compute nodes.

Q: How many of these GPUs can be installed?
A: Up to four H200 NVL cards fit in one UCS X580p PCIe Node, and up to eight GPUs can be used per UCS X9508 chassis with two X580p nodes.

Q: Does it need a software licence?
A: No separate GPU software licence is stated for the card. The host system must be managed in Cisco Intersight Managed Mode, with a minimum Essentials licence per server.

Q: What power does the card draw?
A: The card has a 600W power rating. It is hosted in the UCS X580p PCIe Node, which draws power from the UCS X9508 chassis.
