Cisco UCSC-RAID-SD-D | UCS C240 M7 12G SAS RAID Controller, 4GB FBWC, 28 Drives
SKU:UCSC-RAID-SD-D
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This 12G SAS RAID controller is built for Cisco UCS C240 M7 SFF rack servers. It provides hardware RAID for SAS and SATA hard drives and SSDs, with a 4GB flash-backed write cache protected by a SuperCap. It suits 2U servers that need a large drive count with a protected write cache.
One double-width card manages up to 28 drives, made up of 24 front and 4 rear drives, at 3, 6 and 12 Gbps. Supported RAID levels are 0, 00, 1, 5, 6, 10, 50 and 60, with JBOD mode also available. The controller handles 240 virtual drives, with up to 64 virtual drives per disk group. It does not provide NVMe hardware RAID. This variant differs from the UCSC-RAID-HP 24G Tri-mode controller (14 drives each) and the UCSC-RAID-T-D M6 12G controller (16 drives) by combining 12G SAS with 4GB FBWC and 28-drive capacity.
The controller is selected in place of the Cisco 24G Tri-mode RAID controllers on the UCS C240 M7 SFF (UCSC-C240-M7SX). Only one internal RAID controller can be fitted to the server at a time, and it is managed through Cisco CIMC.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Includes a SuperCap to protect the write cache
- Hardware RAID for SAS/SATA hard drives and SSDs
- One double-width card supports both front and rear drive cages on the C240 M7
- Managed through Cisco CIMC
- Supports JBOD mode alongside RAID 0, 00, 1, 5, 6, 10, 50 and 60
- Only one internal RAID controller can be used at a time in the server
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Interface: SAS 12Gb/s
- Cache: 4GB flash-backed write cache (FBWC) with SuperCap
- Maximum drives: 28 (24 front SAS/SATA + 4 rear)
- Drive speeds supported: 3Gbps, 6Gbps, 12Gbps
- RAID levels: 0, 00, 1, 5, 6, 10, 50, 60 (plus JBOD)
- Virtual drives per controller: 240
- Virtual drives per disk group: up to 64
- NVMe support: No NVMe hardware RAID
- Supported server: UCS C240 M7 SFF (UCSC-C240-M7SX)
- Form factor: Single double-width RAID card serving front and rear drives
- Power: Powered from the server PCIe slot, SuperCap provides write-cache backup power
FAQs
Q: Which servers is this RAID controller for?
A: It is designed for the Cisco UCS C240 M7 SFF rack server (UCSC-C240-M7SX).
Q: How many drives can it manage?
A: Up to 28 SAS or SATA drives, made up of 24 front drives and 4 rear drives, at 3, 6 and 12 Gbps.
Q: Does it support NVMe hardware RAID?
A: No. It provides hardware RAID for SAS and SATA hard drives and SSDs only.
Q: How is the write cache protected?
A: The 4GB flash-backed write cache is protected by a SuperCap, which provides backup power for the cache.
Q: How does it differ from UCSC-RAID-HP and UCSC-RAID-T-D?
A: UCSC-RAID-HP is a 24G Tri-mode controller handling 14 drives each, and UCSC-RAID-T-D is an M6 12G controller handling 16 drives. This controller is 12G SAS with 4GB FBWC and handles up to 28 drives.
Q: Can I fit more than one RAID controller?
A: No. Only one internal RAID controller can be used at a time in the server.
