Cisco UCSC-P-N6D25GF-D | ConnectX-6 Lx 2x25GbE SFP28 Low-Profile NIC, PCIe 4.0 x8
SKU:UCSC-P-N6D25GF-D
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The ConnectX-6 Lx 2x25GbE SFP28 is a dual-port PCIe network interface card from NVIDIA's ConnectX-6 Lx family, supplied by Cisco for UCS C-Series rack servers. It suits enterprise data-centre, cloud and edge servers that need 25GbE connectivity with SDN offload, RoCE and hardware-based security.
The card provides two SFP28 ports that run at 10GbE or 25GbE, giving up to 50 Gb/s of total bandwidth over a PCIe Gen3 and Gen4 x8 host interface. It uses NRZ signalling and a half-height, half-length low-profile form factor. Each SFP28 port can supply up to 1.5 W to the module or cable, and the card draws its power from the PCIe slot. No software licence is required for the NIC itself, and it uses secure boot without crypto.
For optics and cables, the card works with Cisco SFP-10G-SR, SFP-10G-LR, SFP-25G-SR-S, SFP-10/25G-LR-S, the SFP-H10GB and SFP-H25G direct-attach series, and the SFP-25G-AOC and SFP-10G-AOC active optical cables. Break-out and split cables are not supported. Tested switch platforms include the Nexus 93180YC-FX, 93180YC-EX, C93600CD-GX, 5596UP and 5596T.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- NVIDIA ASAP2 SDN data-plane offload (SR-IOV and VirtIO)
- Zero-touch RoCE for RDMA over converged Ethernet
- Inline hardware IPsec encryption and decryption, including IPsec over RoCE
- Connection tracking (L4 firewall) offload
- Overlay network acceleration for VXLAN, GENEVE and NVGRE
- Hierarchical QoS, stateless TCP offloads and flow mirroring and sampling
- Remote boot over Ethernet, iSCSI, UEFI and PXE
- Management via NC-SI, MCTP over SMBus and PCIe, and PLDM monitoring, control and firmware update
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Network ports: 2 x SFP28
- Supported Ethernet speeds: 10GbE, 25GbE
- Total bandwidth: up to 50 Gb/s
- Network interface technology: NRZ
- Host interface: PCIe Gen3 and Gen4, 8 lanes
- Form factor: PCIe HHHL (half-height, half-length), low-profile
- Platform security: hardware root of trust and secure firmware update
- Maximum power available through each SFP28 port: 1.5 W
- Operating temperature: 0 to 55 C (32 to 131 F)
- Non-operating temperature: -40 to 70 C (-40 to 158 F)
- Break-out and split cables: not supported
FAQs
Q: Does this network card need a software licence?
A: No. No software licence is required for the NIC itself. It provides hardware root-of-trust secure boot without crypto.
Q: Which optics and cables work with this card?
A: Cisco SFP-10G-SR, SFP-10G-LR, SFP-25G-SR-S and SFP-10/25G-LR-S optics, SFP-H10GB and SFP-H25G direct-attach cables, and SFP-25G-AOC and SFP-10G-AOC active optical cables. Break-out and split cables are not supported.
Q: How is the card powered?
A: It is powered from the PCIe slot, so no separate power connection is needed. Each SFP28 port can also supply up to 1.5 W to an active module or cable.
Q: Which Cisco switches has this card been tested with?
A: Tested Cisco switches include the Nexus 93180YC-FX, 93180YC-EX, C93600CD-GX, 5596UP and 5596T.
Q: Does the card support RDMA?
A: Yes. It supports zero-touch RoCE for RDMA over converged Ethernet, along with inline IPsec offload and IPsec over RoCE.
