Cisco UCSC-MRAID12G-1GB | UCS C-Series M4 12G SAS RAID Controller, 1GB FBWC
SKU:UCSC-MRAID12G-1GB
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This 12G SAS modular RAID controller is built for Cisco UCS C-Series M4 rack servers, adding hardware RAID and a 1 GB flash-backed write cache. It suits virtualisation, database and storage-heavy workloads that need parity-based RAID with write-back caching.
The 1 GB FBWC option includes 1 GB of cache memory plus a SuperCap that protects cached data if power is lost. With the FBWC fitted, the controller supports JBOD and RAID 0, 1, 10, 5, 6, 50 and 60, extending the base UCSC-MRAID12G controller which is limited to JBOD and RAID 0, 1 and 10. The controller uses a PCIe 3.0 host interface with 12 Gbps SAS connectivity and supports SAS hard disk drives and SAS/SATA solid state drives, up to 24 internal drives depending on the server backplane.
It plugs into the dedicated internal RAID controller slot on the server motherboard and works with the Cisco 12G SAS Modular RAID controller in UCS C220 M4 and C240 M4 rack servers. It is also listed for the C460 M4. The SuperCap mounts on the server air baffle, so no separate power supply is required. It is managed through Cisco CIMC and UCSM.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Flash-backed write cache protects cached data via SuperCap in the event of power loss
- Extends the base 12G SAS RAID controller from RAID 0/1/10 to also support RAID 5, 6, 50 and 60
- Write-back cache capable when the FBWC is installed
- Managed through Cisco CIMC and UCSM
- Supports self-encrypting drives when combined with UCSC-MRAID12G and an FBWC module
- Supports hard disk drives and SAS/SATA solid state drives
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Part number: UCSC-MRAID12G-1GB
- Flash-backed write cache: 1 GB with SuperCap backup
- SAS interface speed: 12 Gbps
- Host interface: PCIe 3.0
- Supported RAID levels: JBOD, 0, 1, 10, 5, 6, 50, 60
- Base controller: Cisco 12G SAS Modular RAID controller (UCSC-MRAID12G)
- Base controller without FBWC: JBOD, RAID 0, 1, 10 only
- Drive support: up to 24 internal SAS HDDs or SAS/SATA SSDs, depending on backplane
- Slot: dedicated internal RAID controller slot on the server motherboard
- Cache backup: SuperCap mounted on the server air baffle
- Spare SuperCap part number: UCSC-MRAID-SC=
- Other cache options: 512 MB, 2 GB and 4 GB versions of the 12G SAS Modular RAID controller
FAQs
Q: Which RAID levels does this FBWC option enable?
A: With the 1 GB FBWC fitted, the controller supports JBOD and RAID 0, 1, 10, 5, 6, 50 and 60. The base UCSC-MRAID12G controller without FBWC supports only JBOD and RAID 0, 1 and 10.
Q: Is this a standalone RAID controller?
A: No. It is ordered with the base Cisco 12G SAS Modular RAID controller (UCSC-MRAID12G) and extends it with a 1 GB flash-backed write cache and SuperCap.
Q: Which servers does it work with?
A: It is used with the UCSC-MRAID12G controller in Cisco UCS C220 M4 and C240 M4 rack servers. It is also listed for the C460 M4.
Q: How is cached data protected during a power loss?
A: A SuperCap power module mounted on the server air baffle protects the cached data if power is lost. No separate power supply is required.
Q: Does it work with the Cisco 12 Gbps Modular SAS HBA?
A: No. This FBWC option is for the 12G SAS Modular RAID controller only. The Modular SAS HBA is JBOD only.
