Cisco UCSC-AD-M6LGPU | UCS C240 M6 LFF PCIe Air Duct, Double-Wide/A10 GPU
SKU:UCSC-AD-M6LGPU
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This PCIe air duct is a mechanical airflow component for the Cisco UCS C240 M6 Large Form Factor (LFF) rack server. It directs cooling air over the PCIe and GPU area when double-wide GPUs or an NVIDIA A10 GPU are fitted, and suits GPU-accelerated deployments such as AI and machine learning inference, VDI and general compute acceleration.
The LFF GPU variant, UCSC-AD-M6LGPU, is the duct specified for double-wide GPU and A10 GPU configurations. It takes the place of the standard LFF PCIe air duct, UCSC-AD-M6L, in GPU-equipped servers, and it is also needed when an A10 GPU is added to an existing server as a later upgrade. It is a passive part with no power draw and needs no licence.
It is designed for the C240 M6 LFF model only, not the SFF model. It is used with the NVIDIA A10 (UCSC-GPU-A10, 150W, 24GB) and other double-wide GPUs, together with the low-profile heatsinks UCSC-HSLP-M6. A server ordered with a GPU ships without the midplane kit, so midplane drives cannot be installed.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Required for double-wide GPU configurations on the UCS C240 M6 LFF server
- Also required when adding an NVIDIA A10 GPU as a later upgrade
- Replaces the standard PCIe air duct (UCSC-AD-M6L) in GPU-equipped LFF servers
- Directs airflow over the PCIe and GPU area for GPU cooling
- Passive mechanical part with no power requirement
- Available as a factory-configured option and as a spare (UCSC-AD-M6LGPU=)
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Part number: UCSC-AD-M6LGPU
- Spare part number: UCSC-AD-M6LGPU=
- Type: PCIe air duct / air baffle
- Description: LFF SKU PCIe Air Duct for Double-Wide GPU and A10 GPU
- Applicable server: Cisco UCS C240 M6 Rack Server, Large Form Factor drive model
- GPU support: double-wide GPUs and NVIDIA A10 GPU
- Standard non-GPU LFF PCIe air duct: UCSC-AD-M6L
- Related heatsink: UCSC-HSLP-M6 low-profile heatsink
- Related A10 GPU: UCSC-GPU-A10 (150W, 24GB)
- Power draw: none, passive component
FAQs
Q: How does this air duct differ from UCSC-AD-M6L?
A: UCSC-AD-M6L is the standard LFF PCIe air duct. UCSC-AD-M6LGPU is the version for LFF servers fitted with double-wide GPUs or an NVIDIA A10 GPU.
Q: Which server is it designed for?
A: It is for the Cisco UCS C240 M6 Large Form Factor (LFF) rack server only, not the SFF model.
Q: Do I need it to add an NVIDIA A10 GPU later?
A: Yes. Cisco specifies this air baffle when adding an A10 GPU to a C240 M6 LFF server.
Q: Does it need a licence or power?
A: No. It is a passive mechanical component with no licence and no power draw. Licences for NVIDIA vGPU or vCompute software, where used, apply to the GPU, not the duct.
Q: What else is used with it in a GPU build?
A: It is used with the UCSC-HSLP-M6 low-profile heatsinks and a GPU such as the NVIDIA A10 (UCSC-GPU-A10). Servers ordered with a GPU ship without the midplane kit, so midplane drives cannot be installed.
