Cisco

Cisco UCS-CPU-I8380 | Xeon Platinum 8380 40-Core 2.3GHz 270W CPU

SKU:UCS-CPU-I8380

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Xeon Platinum 8380 is a 3rd Gen Intel Xeon Scalable (Ice Lake) processor orderable as a Cisco UCS M6-generation server option. It suits dual-socket enterprise servers running virtualisation, databases, analytics and other high core-count, memory-intensive workloads in UCS C-Series rack and B-Series blade servers.

This CPU has 40 cores at a 2.3GHz base clock, a 270W TDP and 60MB of cache. Three UPI links at 11.2 GT/s support 2-socket scaling, and DDR4-3200 memory is supported when 3200MHz DIMMs are installed. Intel Optane Persistent Memory (PMem) is also supported, including mixed DRAM and PMem configurations on M6 platforms. Each CPU provides 16 DIMM sockets on M6 servers, allowing up to 2TB per CPU with 16 x 128GB DRAM.

It is listed as an available CPU for the UCS C220 M6 SFF rack server and the UCS B200 M6 blade server. A separate UCSX-CPU-I8380 SKU covers the UCS X210c M6 compute node. DIMMs run at the lower of the CPU and DIMM clock speeds. No licence or subscription is required.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- 3rd Gen Intel Xeon Scalable (Ice Lake) architecture
- Top-bin 8000 Series core count of 40 cores in the Cisco M6 CPU list
- 3 UPI links at 11.2 GT/s for 2-socket scaling
- DDR4-3200 memory support when 3200MHz DIMMs are installed
- Supports Intel Optane Persistent Memory (PMem)
- Supports mixed DRAM and PMem configurations on M6 platforms

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Product ID (PID): UCS-CPU-I8380
- Processor family: 3rd Gen Intel Xeon Scalable (Ice Lake), 8000 Series Platinum
- Cores: 40
- Clock frequency: 2.3GHz
- Power (TDP): 270W
- Cache size: 60MB
- UPI links: 3 at 11.2 GT/s
- Highest DDR4 DIMM clock support: 3200MHz
- Intel Optane Persistent Memory (PMem) support: Yes
- Chipset on host server (C220 M6 / B200 M6): Intel C621A series (Lewisburg)
- Selectable quantity per server: one or two identical CPUs on 2-socket M6 servers
- Memory per CPU on M6 servers: 16 DIMM sockets, up to 2TB per CPU with 16 x 128GB DRAM

FAQs

Q: Does this CPU need a licence or subscription?
A: No. No licence or subscription is required for this processor.

Q: Which Cisco UCS servers does it work with?
A: It is listed as an available CPU for the UCS C220 M6 SFF rack server and the UCS B200 M6 blade server. The UCS X210c M6 compute node uses the matching UCSX-CPU-I8380 SKU.

Q: Can I install one CPU or do I need two?
A: On 2-socket M6 servers you can select one or two identical CPUs. No single-CPU restriction applies to this SKU.

Q: What memory speed does it support?
A: It supports DDR4 DIMMs up to 3200MHz. If installed DIMMs are rated differently from the CPU, they run at the lower of the two clock speeds.

Q: Does it support Intel Optane Persistent Memory?
A: Yes. It supports Intel Optane Persistent Memory (PMem), including mixed DRAM and PMem configurations on M6 platforms.

Q: What power should I plan for?
A: The CPU has a 270W TDP. Power supply and heatsink selection depend on the host server configuration.
