Cisco

Cisco UCS-CPU-I6416H | Xeon Gold 6416H 18-Core CPU, 2.2GHz, 165W, 45MB

SKU:UCS-CPU-I6416H

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Xeon Gold 6416H is a 4th Gen Intel Xeon Scalable (Sapphire Rapids) processor supplied by Cisco for UCS M7 servers. It is positioned for IMDB and analytics workloads in 2-socket rack server configurations, and suits mixed enterprise, virtualisation and database deployments.

This variant has 18 cores and 36 threads with a 2.2GHz base clock and up to 4.2GHz max turbo. It carries 45MB of L3 cache and a 165W TDP. Memory support is DDR5 RDIMM at up to 4800MT/s at 1DPC, across 8 memory channels per CPU. The processor uses the LGA 4677 socket, offers PCIe 5.0 with up to 80 lanes, and is built on a 10nm process.

UCS-CPU-I6416H is the rack server PID, listed for the Cisco UCS C240 M7 platform. The separate UCSX-CPU-I6416H PID covers UCS X-Series modular compute nodes.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- DDR5 memory support with higher speeds and enhanced memory capacity
- Energy-efficient compute for data centre workloads
- Hardware-enhanced security
- Workload acceleration built into the processor
- Optimised for demanding AI, mainstream data centre, multi-cloud, and network and storage workloads
- 2-socket capable for scale-up IMDB and analytics deployments

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Cisco PID: UCS-CPU-I6416H
- Processor family: Intel Xeon Gold 6416H (4th Gen Xeon Scalable)
- Architecture: Sapphire Rapids
- Cores: 18
- Threads: 36
- Base frequency: 2.20 GHz
- Max turbo frequency: 4.20 GHz
- L3 cache: 45 MB
- TDP: 165 W
- Memory type: DDR5 RDIMM, up to 4800 MT/s (1DPC)
- Memory channels: 8 per CPU
- Socket: LGA 4677
- Process technology: 10 nm
- PCIe: 5.0, up to 80 lanes
- UPI links: up to 4 at 20 GT/s
- Max sockets: 2S
- Intel part number: PK8071305121101

FAQs

Q: Which servers is UCS-CPU-I6416H designed for?
A: It is the rack server PID for Cisco UCS M7 servers, listed in the Cisco UCS C240 M7 SFF specification. UCS X-Series modular compute nodes use the separate UCSX-CPU-I6416H PID.

Q: What memory does this processor support?
A: It supports DDR5 RDIMM at up to 4800MT/s with one DIMM per channel, across 8 memory channels per CPU.

Q: How much power does each processor draw?
A: The TDP is 165W per processor. Allow for this in the server power and cooling budget.

Q: Can it be used in a 2-socket server?
A: Yes. The Xeon Gold 6416H is 2-socket capable and is positioned for IMDB and analytics workloads in 2-socket UCS rack servers.

Q: What socket does it use?
A: It uses the LGA 4677 socket, the 4th Gen Xeon Scalable (Sapphire Rapids) platform.
