Cisco

Cisco NC6-30/60X10G-M-S | 30x10GbE SFP+ (PAYG to 60) | MS (Multi‑Service) | 10GBASE‑SR/LR/ER | 850/1310 nm | reach up to 300 m/10–40 km (optic‑dependent) | LC duplex | license tier: 30‑port base, 60‑port max

SKU:NC6-30/60X10G-M-S

Regular price POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

SFP+ 10GbE line card for NCS 6000 with PAYG scaling—30 active ports, expandable to 60 via licenses. MS profile adds multi‑service capabilities on top of high‑scale IP/MPLS with IOS XR.

Features

- PAYG scaling from 30 to 60 x 10GbE per card
- Multi‑Service profile for advanced service capabilities
- Flexible optic options for short and long reach links
- High reliability and scale with IOS XR
- Standards‑based 10GbE for wide interoperability

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details
  • You may also like
  • Best sellers
  • Related Products

specs-tabs

Collapsible content

FAQs

Technical Specifications

FAQs

Q: What advantages does the MS profile offer?
A: MS enables multi‑service features in addition to IP/MPLS routing, subject to software licensing and configuration.

Q: Are SFP+ modules included?
A: No. Select SR, LR, or ER SFP+ optics according to distance and fiber type.

Q: Is mixing 1G SFP with 10G SFP+ supported?
A: Support for 1G on SFP+ slots is platform and software dependent. Consult the hardware/IOS XR release notes.

Q: How do I expand from 30 to 60 ports?
A: Purchase and apply the appropriate software licenses to activate additional ports, up to 60 total.

Q: What IOS XR version is required?
A: Use a release that explicitly lists support for this line card; check the official release notes.

Technical Specifications

- Port density: 30 x 10GbE SFP+ active (expandable to 60 with licenses)
- Line card role: MS (Multi‑Service) profile
- Interface type: SFP+ slots for 10G optics
- Supported 10G standards: 10GBASE-SR, 10GBASE-LR, 10GBASE-ER (optic-dependent)
- Typical wavelengths: 850 nm (SR), 1310 nm (LR/ER)
- Optical reach: up to ~300 m on MMF (SR), up to 10 km (LR), up to 40 km (ER), optic-dependent
- Connector type (optics): LC duplex
- OS compatibility: Cisco IOS XR (release-dependent)
- Chassis compatibility: NCS 6000 Series slots
- Licensing: PAYG—30 ports included; software licenses enable up to 60 ports
