• Cisco NC6-20X100GE-L-C 20-port 100GbE switch with sleek black design
1 1

Cisco

Cisco NC6-20X100GE-L-C | 20x100GbE | LSR | 100G pluggables (CFP2/CPAK, optic-dependent) | 100GBASE-LR4/SR10/ER4 | 1310/850 nm | reach up to 10–40 km | LC duplex/MPO connectors | license: 20x100G active

NC6-20X100GE-L-C

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

High‑density 100GbE line card for NCS 6000 core deployments, delivering 20 ports of 100G with combo optic receptacles to support both LR4/ER4 (LC) and SR10 (MPO), optic‑dependent. LSR profile optimized for IP/MPLS label switching with IOS XR.

Features

- 20 x 100GbE ports for dense core aggregation
- Combo optic receptacles support LR4/ER4 (LC) and SR10 (MPO), optic-dependent
- LSR forwarding profile for efficient MPLS/IPv4/IPv6 core
- IOS XR feature set with robust routing scale
- Standards-based 100G optics for flexible reach options

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Port density: 20 x 100 Gigabit Ethernet
- Line card role: LSR (Label Switch Router) profile
- Optic bays: 100G pluggable combo (LC duplex for LR4/ER4; MPO/MTP for SR10), optic-dependent
- Supported 100G standards: 100GBASE-LR4, 100GBASE-ER4, 100GBASE-SR10 (optic-dependent)
- Typical wavelengths: 1310 nm (LR4/ER4), 850 nm (SR10)
- Optical reach: up to 10 km (LR4), up to 40 km (ER4), MMF short‑reach for SR10 (optic/media-dependent)
- Connector types: LC duplex (LR4/ER4), MPO/MTP (SR10)
- OS compatibility: Cisco IOS XR (release-dependent)
- Chassis compatibility: NCS 6000 Series slots (fabric/PEM requirements per chassis)
- Licensing: 20 x 100G ports active (no PAYG on this model)

FAQs

Q: Are optics included with the line card?
A: No. 100G optics are sold separately. Choose LR4/ER4 (LC) or SR10 (MPO) as required.

Q: What is the difference between LSR and MS variants?
A: LSR is optimized for high-performance IP/MPLS label switching. MS (Multi‑Service) variants add broader service features and interfaces, depending on software licensing.

Q: Does this card support 100G to 10x10G breakout?
A: Breakout capability is optic- and platform-dependent. In routed deployments, ports typically operate as 100G. Verify in the platform and optic release notes.

Q: Which software is required?
A: A supported Cisco IOS XR release for NCS 6000 is required. Check the specific release notes for this line card.

Q: Is this card compatible with all NCS 6000 chassis?
A: It is designed for NCS 6000 Series. Ensure your chassis and fabric/PEM configuration meet the power and fabric bandwidth requirements.
