• Black cisco c9k-pwr-1100wdc catalyst 9550 1100w dc titanium power supply back with honeycomb grille and cable connectors
1 1

Cisco

Cisco C9K-PWR-1100WDC | Catalyst 9550 1100W DC Titanium Power Supply

C9K-PWR-1100WDC

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The C9K-PWR-1100WDC is a hot-swappable internal 1100W DC power supply module for Cisco Catalyst 9550 Series smart switches. It is Titanium-certified for power efficiency and has a port-side exhaust fan. It suits campus LAN core and distribution deployments that are powered from a DC source and need redundant power supplies.

Each C9550 chassis has two power supply slots, numbered 0 to 1 from left to right, and the module supports 1+1 redundancy. On the C9550-24L4CD and C9550-48L4CD it can be paired with a 750W AC module or a second 1100W DC module. On the C9550-96L4D it can be paired with an 1100W AC module or a second 1100W DC module. This is the 1100W DC variant, so it is the part to choose for DC-fed sites rather than the default AC supplies.

The module works with fan trays that have port-side intake (burgundy) and port-side exhaust (blue) airflow. A status LED shows normal, warning and fault states, and a blue beacon identifies the slot needing attention. An extraction handle makes replacement straightforward. Any empty power supply slot must be filled with a blank module.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Titanium-certified power efficiency
- Supports 1+1 power supply redundancy
- Hot-swappable internal module
- Status LED shows normal, warning and fault conditions
- Blue beacon identifies the module needing attention
- Extraction handle for module replacement
- Works with port-side intake and port-side exhaust fan airflow
- Can be mixed with AC power supply modules in supported combinations

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Part number: C9K-PWR-1100WDC
- Power type: 1100W DC input
- Efficiency certification: Titanium
- Airflow: Port-side exhaust fan
- Fan compatibility: port-side intake (burgundy) and port-side exhaust (blue) fans
- Form: Hot-swappable internal power supply module
- Power supply slots per switch: 2 (numbered 0 to 1, left to right)
- Redundancy: 1+1
- Supported switches: C9550-24L4CD, C9550-48L4CD, C9550-96L4D
- Supported combinations (24L4CD / 48L4CD): 750W AC + 1100W DC; 1100W DC + 1100W DC
- Supported combinations (96L4D): 1100W AC + 1100W DC; 1100W DC + 1100W DC
- Module features: status LED, blue beacon, air vent, extraction handle, serial number location

FAQs

Q: Which switches does the C9K-PWR-1100WDC fit?
A: It fits the Cisco Catalyst C9550-24L4CD, C9550-48L4CD and C9550-96L4D smart switches.

Q: Can I mix it with an AC power supply?
A: Yes, in supported combinations. The C9550-24L4CD and C9550-48L4CD support 750W AC + 1100W DC, and the C9550-96L4D supports 1100W AC + 1100W DC. Two 1100W DC modules are also supported on all three models.

Q: Is this the default power supply on the C9550?
A: No. The default supply is 750W AC on the C9550-24L4CD and C9550-48L4CD, and 1100W AC on the C9550-96L4D. This module is the DC option.

Q: Does it support power supply redundancy?
A: Yes. Each chassis has two power supply slots and the module supports 1+1 redundancy.

Q: Which fan airflow does it work with?
A: It works with fans that have port-side intake (burgundy) and port-side exhaust (blue) airflow.

Q: What happens if I only install one power supply?
A: Any empty power supply slot must be filled with a blank module.
