Aruba

Aruba R4D62A | MPO-12 to 4x LC duplex breakout, OS2 single-mode, 2m, 9/125 um, MPO female to LC UPC

SKU:R4D62A

Regular price POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

High-density single-mode breakout harness for splitting a 12-fiber MPO trunk or MPO-enabled port into four LC duplex connections. Ideal for leaf-spine aggregation, patch panels, and equipment with MPO front ends feeding LC-based optics or ports. Factory-terminated and tested for low loss and consistent performance.

Features

- High-density MPO-to-LC breakout for efficient rack cabling
- Low-loss terminations for stable single-mode performance
- Factory-tested for insertion loss and end-face quality
- Simplifies migration between MPO backbones and LC equipment
- Tool-less deployment; plug-and-play in patch panels and switch ports

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details
  • You may also like
  • Best sellers
  • Related Products

specs-tabs

Collapsible content

FAQs

Technical Specifications

FAQs

Q: Is the MPO end male or female?
A: Female (no pins). This mates with MPO ports or cassettes that have guide pins.

Q: What polish type are the LC connectors?
A: LC UPC to match common single-mode port requirements.

Q: Can this be used to connect an MPO-based device to four LC ports?
A: Yes, it breaks out one MPO-12 into four LC duplex legs for equipment or panel LC ports.

Q: Does it support OS2 single-mode wavelengths?
A: Yes, it supports standard single-mode wavelengths such as 1310 nm and 1550 nm.

Q: Is polarity specified?
A: This is a straight breakout harness; final polarity depends on the overall link design and any cassettes or trunks used.

Technical Specifications

- Cable type: MPO-12 to 4x LC duplex single-mode breakout (harness)
- Fiber type: OS2, 9/125 um
- Length: 2 m
- Connectors: MPO-12 female (no pins) to 4x LC UPC
- Fanout: 8 fibers active across 4 duplex LC legs
- Application: split an MPO trunk or transceiver-facing MPO port into four LC ports
- Standards: IEC 61754-7 (MPO), IEC 61754-20 (LC), TIA-568.3-D
- Compliance: RoHS
- Test: factory-terminated and performance-tested
