NVIDIA MTQ8100-HS2F | MetroX-2 10-Port InfiniBand Switch, 10km, P2C, 2 PSU

MTQ8100-HS2F

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The MTQ8100-HS2F is a 1U NVIDIA Quantum MetroX-2 long-haul InfiniBand switch that extends HDR fabrics between remote data centres. It combines two 100Gb/s long-reach QSFP28 ports supporting links up to 10 km with eight local HDR QSFP56 ports, delivering RDMA and SHARP over distance. This variant ships with two hot-swappable AC power supplies, P2C airflow, a standard-depth chassis and a rail kit.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Extends InfiniBand connectivity to 10 or 40 km using LR4 Quantum Long Reach transceivers
- Native RDMA over long distance
- SHARP offloads collective operations from the CPU to the switch network
- Adaptive Routing selects the output port based on port load
- Congestion Control reduces packet drops and congestion spreading
- SHIELD self-healing interconnect enhancement
- 1+1 redundant hot-swappable power supplies and N+1 hot-swappable fans
- 80 Plus Gold and Energy Star certified power supplies

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 2 x long-haul QSFP28 ports, 100Gb/s, up to 10 km
- 8 x standard HDR QSFP56 local ports, 40/56/100/200Gb/s per port
- 10 QSFP cages in total
- Switching throughput: 4Tb/s
- CPU: x86 ComEx Broadwell D-1508, 2.2GHz, dual core
- Memory: 8GB
- Software: MLNX-OS
- Management: 1 x RJ45, 1 x RS232 console, 1 x micro USB
- 2 x AC power supplies (1+1 redundant, hot-swappable)
- P2C airflow with N+1 hot-swappable fans
- Form factor: 1U, 19-inch rack mount, standard depth, rail kit included
- Dimensions: 88 mm H x 438 mm W x 760 mm D
- Max power consumption: 600W with AOCs, 538W with DACs
- Operating temperature: 0 to 40°C
- EMC: CE, FCC, VCCI, ICES, RCM

FAQs

Q: How far can the long-haul ports of the MTQ8100-HS2F reach?
A: The two long-haul QSFP28 ports run at 100Gb/s and support links up to 10 km. Longer reach to 40 km is possible using LR4 Quantum Long Reach transceivers.

Q: What local ports does this switch provide?
A: It has eight standard HDR QSFP56 ports that operate at 40, 56, 100 or 200Gb/s per port for connecting local InfiniBand equipment.

Q: What airflow and power configuration does this variant use?
A: This model uses P2C (power-to-connector) airflow with N+1 hot-swappable fans and two 1+1 redundant hot-swappable AC power supplies.

Q: Does it support RDMA and in-network computing across sites?
A: Yes. It supports native RDMA over long distance and SHARP, which offloads collective operations from the CPU to the switch network.

Q: Is a rail kit included for rack mounting?
A: Yes. This variant is a 1U, 19-inch rack-mount, standard-depth unit supplied with a rail kit.
