NVIDIA 980-9I17S-00HS00 | LinkX 100G QSFP28 LR4 Transceiver, SMF 10km, LC
SKU:980-9I17S-00HS00
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This LinkX 100G QSFP28 LR4 transceiver is a single-mode optical module for 100GbE links up to 10km over duplex LC fibre. It suits data centre interconnect and campus or metro reach links where multimode optics fall short, and it is also qualified for InfiniBand EDR systems.
The module converts four 25.78Gb/s electrical lanes to 1310nm LAN-WDM optical signals, giving a combined 100Gb/s. It follows 100GBASE-LR4 (IEEE 802.3ba) and CAUI-4 (IEEE 802.3bm), uses a hot-pluggable QSFP28 form factor, and draws less than 3.5W from a single +3.3V supply. Operating case temperature is 0 to 70 C, and digital diagnostic monitoring is available over I2C.
It connects to 100GbE QSFP28 ports and requires G.652 single-mode duplex LC fibre at both ends of the link.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-pluggable QSFP28 MSA form factor
- Up to 10km reach over single-mode fibre
- Digital diagnostic monitoring via I2C per SFF-8636
- Qualified for InfiniBand EDR end-to-end systems
- 100GBASE-LR4 and CAUI-4 compliant
- Low power draw of under 3.5W
- RoHS compliant
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Form factor: Hot-pluggable QSFP28 (QSFP28 MSA)
- Data rate: 100Gb/s (4 x 25.78125Gb/s lanes)
- Standards: IEEE 802.3ba 100GBASE-LR4, IEEE 802.3bm CAUI-4
- Fibre type: Single-mode (G.652)
- Maximum link distance: 10km
- Connector: Duplex LC
- Nominal wavelength: 1310nm LAN-WDM
- Transmitter: 4 x 25.78Gb/s DFB-based
- Electrical interface: 4 x 25.78Gb/s retimed
- Supply voltage: +3.3V (3.135 to 3.465V)
- Maximum power consumption: below 3.5W
- Operating case temperature: 0 to 70 C
- Storage temperature: -40 to 85 C
- Relative humidity (non-condensing): 15 to 85%
- Digital diagnostics: SFF-8636 DDM via I2C
- Compliance: RoHS
FAQs
Q: What fibre does this transceiver need?
A: It requires G.652 single-mode fibre with duplex LC connectors. It supports links up to 10km.
Q: Which ports does it work with?
A: It works with 100GbE QSFP28 ports and is also qualified for InfiniBand EDR end-to-end systems.
Q: How much power does it draw?
A: It runs from a single +3.3V supply with a maximum power consumption below 3.5W.
Q: Does it support digital diagnostics?
A: Yes. Digital diagnostic monitoring is available over I2C, compliant with SFF-8636.
