NVIDIA 930-9BBRK-00L3-000 | Full-Height Bracket for ConnectX-6 NICs, 1x QSFP28

930-9BBRK-00L3-000

Stock Status: Enquire

$28.60 inc. GST
$26.00 ex. GST
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This full-height PCIe bracket is designed as a field-replaceable accessory for NVIDIA ConnectX-6 network adapter cards. Featuring a single QSFP/QSFP28 port cutout and dual LED windows, it enables proper installation of compatible single-port ConnectX-6 adapters in standard rackmount servers and workstations. Compatible with MCX651105A, MCX623105A, and MCX683105A adapter models.

Features

Standard full-height PCIe bracket design for rackmount server compatibility
- Single QSFP/QSFP28 port cutout for network connectivity access
- Dual LED indicator windows for link status and activity monitoring
- Perforated metal construction for improved airflow
- Field-replaceable unit design for easy installation and swapping
- Compatible with ConnectX-6 single-port 100GbE and 200GbE adapters
- Precision-engineered mounting holes for secure chassis attachment

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

Bracket Type: Full-height (tall) PCIe bracket
- Port Cutouts: 1x QSFP/QSFP28 port opening
- LED Windows: Dual LED indicator windows
- Compatible Models: MCX651105A, MCX623105A, MCX683105A
- Material: Metal construction with perforated design
- Form Factor: Standard full-height PCIe slot profile
- Application: Field-replaceable unit (FRU) for NVIDIA ConnectX-6 adapter cards

FAQs

Q: Which NVIDIA adapter cards is this bracket compatible with?
A: This full-height bracket is compatible with NVIDIA ConnectX-6 adapter models MCX651105A-EDAT, MCX623105A, and MCX683105AN-HDAT. These are single-port QSFP56/QSFP28 network adapters supporting 100GbE to 200GbE connectivity.

Q: What is the difference between full-height and low-profile brackets?
A: Full-height (tall) brackets are designed for standard rackmount servers and tower workstations with full-size PCIe slots. Low-profile (short) brackets are used in compact chassis and small form factor systems. This is the tall bracket variant.

Q: Can I use this bracket to convert my adapter card for a different chassis type?
A: Yes, this bracket allows you to install compatible ConnectX-6 adapter cards in full-height PCIe slots. If your adapter came with a low-profile bracket installed, you can swap it with this full-height bracket for standard server installations.

Q: Does this bracket support dual-port ConnectX-6 adapters?
A: No, this bracket features a single QSFP/QSFP28 port cutout and is designed specifically for single-port ConnectX-6 models. Dual-port adapters require a different bracket design with two port openings.
