NVIDIA

NVIDIA 920-9N110-00R1-0C0 | Spectrum SN2201 48-Port 1G Switch, 4x 100G, C2P

920-9N110-00R1-0C0

Stock Status: Enquire

$6,578.00 inc. GST
$5,980.00 ex. GST
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The NVIDIA Spectrum SN2201 is a 1U Open Ethernet switch with 48 x 10/100/1000Base-T RJ45 ports and 4 x 100GbE QSFP28 uplinks, built on the Spectrum ASIC. It suits top-of-rack and out-of-band management deployments and comes preloaded with Cumulus Linux. This variant includes dual hot-swappable AC power supplies, connector-to-power (C2P) airflow and a 4-post rail kit, distinguishing it from the P2C airflow version.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Preloaded with Cumulus Linux, with ONIE bootloader and SONiC support
- ASIC-level telemetry with NVIDIA What Just Happened (WJH)
- Non-blocking 100GbE uplinks for spine and aggregation connectivity
- Suited to top-of-rack (up to 48 x 1GbE hosts) or out-of-band management roles
- Dual hot-swappable redundant power supplies

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- 48 x RJ45 10/100/1000Base-T ports
- 4 x QSFP28 ports, each supporting 1/10/25/40/50/56/100GbE
- Switching capacity: 448 Gbps
- Up to 667 Mpps
- Spectrum ASIC with 16MB fully shared packet buffer
- CPU: Intel x86 dual core
- Memory: 8GB ECC DDR4 SO-DIMM
- Storage: 20GB M.2 PCIe Gen3 SSD
- Dual AC power supplies (1+1 redundant, hot-swappable), 4 fans
- Power input: 100-127V AC 50/60Hz 4A (x2), 200-240V AC 50/60Hz 2A (x2)
- Typical power consumption: 98W with passive cables
- Dimensions (HxWxD): 43.9 x 428 x 432 mm, short depth, 1U, 19-inch rack mount
- Weight: approx. 7.41 kg
- Airflow: connector-to-power (C2P)
- 4-post rail kit included
- Operating temperature: 0°C to 40°C
- Non-PoE

FAQs

Q: What operating system does this switch run?
A: It is preloaded with Cumulus Linux and also supports the ONIE bootloader and SONiC.

Q: What speeds do the QSFP28 uplink ports support?
A: Each of the 4 QSFP28 ports supports 1/10/25/40/50/56/100GbE.

Q: How does this SKU differ from 920-9N110-00F1-0C0?
A: This SKU uses connector-to-power (C2P) airflow, while 920-9N110-00F1-0C0 uses power-to-connector (P2C) airflow. Both are variants of the SN2201 platform.

Q: Does this switch support PoE?
A: No. The 48 RJ45 ports are standard 10/100/1000Base-T and do not provide Power over Ethernet.

Q: Is a rack mount kit included?
A: Yes. A 4-post rail kit is included for 19-inch rack installation in this 1U short-depth chassis.
