• NVIDIA Xavier NX 16GB Dev Kit with Santa Clara GPU module
1 1

NVIDIA

NVIDIA 900-83668-0030-000 | Jetson Xavier NX 16GB AI Development Kit, 21 TOPS

900-83668-0030-000

Stock Status: Enquire

$1,701.43 inc. GST
$1,546.75 ex. GST
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The NVIDIA Jetson Xavier NX 16GB Developer Kit delivers edge AI supercomputing with up to 21 TOPS of performance in a compact development platform. Built around the credit-card-sized Xavier NX module featuring a 6-core Carmel CPU, 384-core Volta GPU with 48 Tensor Cores, and 16GB LPDDR4x memory, this kit accelerates development of multi-modal AI applications for robotics, industrial automation, smart cities, and embedded vision systems. The reference carrier board provides comprehensive I/O including Gigabit Ethernet, USB 3.0, HDMI 2.0, DisplayPort, M.2 NVMe storage expansion, and multiple camera interfaces.

Features

21 TOPS AI performance for real-time inference of multiple neural networks
- 384-core Volta GPU with 48 Tensor Cores for accelerated deep learning
- Dual NVDLA engines and 2x PVA vision accelerators for dedicated AI processing
- 6-core 64-bit ARM Carmel CPU with power-efficient architecture
- 16GB LPDDR4x memory with 51.2GB/s bandwidth for high-resolution sensor data
- Multi-camera support: up to 6 cameras (MIPI CSI-2) for computer vision applications
- Hardware video encode/decode: H.265, H.264, VP9 up to 4K60
- PCIe Gen3 and Gen4 expansion for NVMe storage and custom peripherals
- Pre-installed 802.11ac WiFi and Bluetooth 5.0 connectivity
- microSD boot support for rapid OS deployment and development
- M.2 NVMe SSD expansion for high-speed local storage
- Comprehensive JetPack SDK support with CUDA, TensorRT, and DeepStream
- Cloud-native container support (Docker, Kubernetes) for modern DevOps workflows
- 40-pin GPIO header for custom sensor and actuator integration
- Multiple power modes (10W/15W/20W) for flexible thermal and battery design

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

AI Performance: Up to 21 TOPS at 15W/20W, 14 TOPS at 10W
- GPU: 384-core NVIDIA Volta with 48 Tensor Cores, 2x NVDLA engines
- CPU: 6-core NVIDIA Carmel ARM v8.2 64-bit processor
- Memory: 16GB 128-bit LPDDR4x at 51.2GB/s bandwidth
- Storage: 16GB eMMC 5.1 onboard, microSD card slot, M.2 Key M NVMe expansion
- Network: Gigabit Ethernet (10/100/1000 BASE-T)
- USB: 4x USB 3.1, 1x USB 2.0 Micro-B
- Display: HDMI 2.0, DisplayPort 1.2
- Camera Support: Up to 6 cameras via MIPI CSI-2 (24 via virtual channels)
- Expansion: M.2 Key E (PCIe x1, USB 2.0 for WiFi/BT), 40-pin GPIO header
- Power Input: 19V DC via barrel jack (power supply included)
- Module Dimensions: 45mm x 69.6mm
- Operating Temperature: 0°C to 50°C (module rating varies by power mode)
- Includes: Xavier NX 16GB module with heatsink, reference carrier board (P3509-0000), 802.11ac WiFi/Bluetooth module, 19V power supply

FAQs

Q: What is the difference between 10W and 20W power modes?
A: The Xavier NX 16GB supports multiple power modes: 10W mode delivers 14 TOPS for battery-operated or thermally constrained applications, while 15W and 20W modes unlock the full 21 TOPS performance for maximum AI inference throughput. Power mode selection is configurable via software based on your thermal and power budget requirements.

Q: Can I use this developer kit for production deployment?
A: The developer kit is designed for software development, prototyping, and evaluation. The included Xavier NX module (P3668-0000) is a non-production specification variant intended for development use. For production deployments, use production-grade Xavier NX modules with a custom or commercial carrier board tailored to your application requirements.

Q: What software and development tools are supported?
A: The Xavier NX Developer Kit is supported by NVIDIA JetPack SDK, which includes Ubuntu Linux, CUDA, cuDNN, TensorRT, DeepStream SDK, and comprehensive libraries for computer vision, AI, and multimedia. JetPack can be installed via SD card image or NVIDIA SDK Manager running on an Ubuntu host PC.

Q: How many neural networks can run simultaneously?
A: The Xavier NX can run multiple modern neural networks in parallel thanks to its 384 CUDA cores, 48 Tensor Cores, and dual NVDLA deep learning accelerators. Actual concurrent network capacity depends on model complexity, resolution, and frame rate requirements, but typical deployments successfully run 3-5+ concurrent AI models for multi-sensor fusion applications.

Q: Is the Xavier NX compatible with Jetson Nano carrier boards?
A: The Xavier NX module uses a different form factor and connector than Jetson Nano, so direct mechanical compatibility is limited. However, many third-party carrier boards are designed to support both Nano and Xavier NX modules via compatible 260-pin SO-DIMM connectors, allowing you to scale from Nano to Xavier NX on the same carrier platform.
