• Meraki MS150-24MP-4X cloud-managed switch with PoE ports
1 1

Meraki

Meraki MS150-24MP-4X | Meraki MS150 24-Port Switch, 16x 1G + 8x 5G, 370W PoE++

MS150-24MP-4X

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Meraki MS150-24MP-4X is a cloud-managed Layer 2 access switch designed for enterprise branch and campus deployments. It combines 16 Gigabit Ethernet ports and 8 multi-gigabit ports with 370W PoE++ budget, delivering up to 60W per port on the 5G mGig ports for Wi-Fi 7 access points, IP cameras, and IoT devices. With 4x 10G SFP+ uplinks and 80Gbps stacking capability, it provides scalable performance and centralized management through the Meraki Dashboard.

Features

Cloud-managed via Meraki Dashboard with zero-touch provisioning
- Layer 2 switching with static routing and DHCP server capabilities
- 802.1Q VLAN tagging and trunking
- 802.1X authentication for secure network access
- DHCP snooping and Dynamic ARP Inspection (DAI)
- Adaptive Policy for application-level segmentation
- Broadcast storm control and IPv4/IPv6 ACL support
- Perpetual PoE and Fast PoE for continuous device power
- Automatic firmware updates and remote troubleshooting tools
- SNMP and Syslog integration for remote management
- Non-blocking switch fabric with 272 Gbps switching capacity
- Quality of Service (QoS) for traffic prioritization
- Stackable architecture with 80 Gbps stacking bandwidth per unit

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

Port Configuration: 16x 10/100/1000 Mbps RJ45, 8x 100M/1G/2.5G/5G mGig RJ45 (ports 17-24)
- Uplinks: 4x 10G SFP+ fiber ports
- PoE Budget: 370W total (PoE+ up to 30W on ports 1-16, PoE++ up to 60W on ports 17-24)
- Switching Capacity: 272 Gbps
- Forwarding Rate: 202.38 Mpps (single switch), 440.47 Mpps (stacked)
- Stacking: 2x dedicated stacking ports, 80 Gbps stacking bandwidth, up to 8 switches per stack
- Layer 3 Features: Static routing, DHCP server
- Management: Cloud-managed via Meraki Dashboard
- Dimensions: 1.73 x 17.32 x 15.75 in (44 x 440 x 400 mm)
- Power Input: AC 100-240V
- Operating Temperature: 0°C to 45°C

FAQs

Q: What PoE capabilities does the MS150-24MP-4X support?
A: The switch delivers PoE+ (up to 30W) on ports 1-16 and PoE++ (up to 60W) on ports 17-24, with a total 370W power budget. The 60W PoE++ ports are ideal for powering Wi-Fi 7 access points, PTZ cameras, and other high-power devices.

Q: Which ports support multi-gigabit speeds?
A: Ports 17-24 are multi-gigabit ports supporting 100M/1G/2.5G/5G speeds, while ports 1-16 are standard Gigabit Ethernet ports. This configuration provides flexible connectivity for both legacy devices and next-generation equipment.

Q: Can I stack multiple MS150-24MP-4X switches?
A: Yes, you can stack up to 8 MS150 switches using the two dedicated stacking ports with 80 Gbps stacking bandwidth per switch. Use compatible QSFP28 stacking cables for physical backplane stacking.

Q: What licensing is required for the MS150-24MP-4X?
A: The switch requires a Meraki MS Enterprise or Advanced license for cloud management and operation. Licenses are available in 1, 3, 5, 7, and 10-year terms and must be purchased separately from the hardware.

Q: Is the MS150-24MP-4X suitable for campus and branch deployments?
A: Absolutely. The MS150-24MP-4X is purpose-built for branch and campus access layer deployments, offering zero-touch provisioning, centralized cloud management, and sufficient PoE budget to support wireless access points, IP phones, cameras, and IoT devices.
