• White Cisco Meraki MR46E-HW Wi-Fi 6 access point with four antennas
1 1

Meraki

Meraki MR46E-HW | MR46E Wi-Fi 6 Access Point, 4x4:4, 3.55 Gbps, External Antennas

MR46E-HW

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The Meraki MR46E is a cloud-managed Wi-Fi 6 access point designed for high-density enterprise deployments in offices, schools, hospitals, and hotels. Featuring 4x4:4 MU-MIMO with up to 3.55 Gbps aggregate throughput, external antenna connectors for flexible RF coverage, and a 2.5 Gbps multigigabit Ethernet port, it delivers exceptional wireless performance. With dedicated radios for security scanning and Bluetooth Low Energy, the MR46E provides comprehensive wireless infrastructure for demanding environments.

Features

Wi-Fi 6 (802.11ax) with OFDMA and MU-MIMO for efficient multi-client transmission
- 4x4:4 spatial streams on both 2.4 GHz and 5 GHz radios
- Dedicated third radio for 24/7 wireless intrusion detection (WIDS/WIPS) and spectrum analysis
- Integrated Bluetooth Low Energy radio for IoT visibility, location analytics, and beacon services
- External antenna connectors for flexible RF design and coverage optimization
- 2.5 Gbps multigigabit Ethernet for full Wi-Fi 6 throughput without bottlenecks
- Cloud-managed with zero-touch provisioning and automatic firmware updates
- Advanced security: WPA3, 802.1X, AES hardware encryption, Layer 7 firewall
- Transmit beamforming and enhanced receive sensitivity for extended range
- Automatic RF optimization powered by cloud analytics
- Application-aware traffic shaping and bandwidth controls
- Guest access with portal customization and splash page support
- Integration with Active Directory, RADIUS, and EMM/MDM platforms
- Real-time client visibility, usage analytics, and anomaly detection
- PCI compliance reporting for retail and payment card environments
- Support for 802.11k/r/v for fast roaming and optimized client connections

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Datasheet

Technical Specifications

Wi-Fi Standard: 802.11ax (Wi-Fi 6), dual-band 2.4 GHz and 5 GHz
- Radio Configuration: 4x4:4 MU-MIMO with OFDMA support
- Aggregate Frame Rate: Up to 3.55 Gbps dual-radio (2.4 Gbps on 5 GHz, 1.15 Gbps on 2.4 GHz)
- Ethernet Interface: 1x 2.5 Gbps multigigabit RJ45 port
- Antenna Connectors: 6x RP-TNC external antenna connectors (antennas sold separately)
- Additional Radios: Dedicated dual-band WIDS/WIPS and spectrum analysis radio, integrated Bluetooth Low Energy radio
- Power Requirements: 802.3at PoE+ (42.5-57V) or 12V DC adapter (sold separately)
- Power Consumption: 18W typical
- Dimensions: 290 x 140 x 37 mm (11.4 x 5.5 x 1.5 in)
- Weight: 0.9 kg (2.0 lb)
- Operating Temperature: 0°C to 45°C (32°F to 113°F)
- Humidity: 5% to 95% non-condensing
- Management: Cloud-managed via Meraki Dashboard (license required)
- Mounting: Ceiling, wall, or rail mountable
- Certifications: FCC, CE, IC, EN 60601-1-2 (medical environments)

FAQs

Q: Does the MR46E-HW include antennas?
A: No, the MR46E-HW features external antenna connectors (6x RP-TNC) and requires Meraki antennas to be purchased separately. Compatible antenna options include MA-ANT-3-A6, MA-ANT-3-B6, MA-ANT-3-C6, MA-ANT-3-D6, MA-ANT-3-E6, and MA-ANT-3-F6, each designed for different coverage patterns and deployment scenarios.

Q: What is the difference between the MR46 and MR46E?
A: The MR46 has integrated internal antennas, while the MR46E has external antenna connectors. The MR46E is ideal for deployments requiring customized RF coverage, directional antennas, or challenging RF environments where antenna placement and type need to be optimized for specific spatial layouts.

Q: Is a Meraki license required to operate the MR46E?
A: Yes, a Meraki Enterprise or Advanced license is required for the MR46E to function. The license is purchased on a per-device, per-year basis and includes cloud management, firmware updates, 24/7 monitoring, support, and access to all Meraki Dashboard features. The access point will not operate without an active license.

Q: What power options are available for the MR46E-HW?
A: The MR46E-HW supports 802.3at PoE+ power over the Ethernet port or can be powered via a 12V DC adapter (MA-PWR-30W). For deployments without PoE switches, Meraki offers PoE injectors: MA-INJ-4 for Gigabit and MA-INJ-5 for multigigabit connections.

Q: Can the MR46E support high-density environments?
A: Yes, the MR46E is specifically designed for high-density deployments with 4x4:4 MU-MIMO and OFDMA technology to serve multiple clients simultaneously. The dedicated third radio provides continuous RF optimization and wireless security without impacting client throughput, making it ideal for venues with hundreds of concurrent users.

Datasheet

This product has a detailed PDF datasheet available. Open PDF datasheet in a new tab .

Your browser can’t display the embedded PDF. Click here to open it in a new tab.
