• Meraki MA-ANT-3-A1 white plastic dipole antenna with hexagonal RP-TNC connector
1 1

Meraki

Meraki MA-ANT-3-A1 | Indoor Dual-Band Dipole Antenna, 3.8/5.5 dBi, RP-TNC

MA-ANT-3-A1

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The Meraki MA-ANT-3-A1 is a fixed indoor dual-band dipole antenna, supplied as a single unit. It is an omnidirectional antenna for the Meraki MR Series, designed for low-ceiling installations where wall penetration or extended reach matters, such as schools and hotels that cover adjacent rooms from APs mounted in hallways.

The antenna covers both the 2.4 GHz and 5 GHz bands, with 3.8 dBi gain on 2.4 GHz and 5.5 dBi gain on 5 GHz. It has linear vertical and horizontal polarisation, an omnidirectional horizontal pattern and a 40 degree vertical beamwidth. It connects through an RP-TNC connector and is a passive accessory with no power requirement or licence of its own. The compact PC-ABS body measures 77.7 mm by 14.5 mm and weighs 21.59 g.

This 1-pack version is intended for Meraki indoor access points with external antenna ports, including the MR42E and MR53E. Five-pack and six-pack versions are available separately as MA-ANT-3-A5 and MA-ANT-3-A6.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- 360-degree omnidirectional coverage
- Dual-band operation on 2.4 GHz and 5 GHz
- Suited to low-ceiling installations where wall penetration or extended reach is important
- Fits low-density deployments such as schools and hotels that need basic connectivity
- Fixed dipole design with RP-TNC connector
- Passive antenna with no power requirement

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Antenna type: Dipole, omnidirectional
- Frequency range: 2.400 - 2.500 GHz, 5.150 - 5.875 GHz
- Gain: 3.8 dBi (2.4 GHz) / 5.5 dBi (5 GHz)
- Connector: RP-TNC
- Polarisation: Linear, vertical/horizontal
- Horizontal beamwidth: Omnidirectional
- Vertical beamwidth: 40 degrees
- Pack quantity: 1
- Dimensions: 77.7 mm x 14.5 mm (3.05 in x 0.57 in)
- Weight: 21.59 g (0.76 oz)
- Material: PC-ABS
- Operating temperature: 0 to 40 C (32 to 104 F)
- Humidity: 5% to 95%
- Environment: Indoor use
- Power: Passive, no power requirement

FAQs

Q: Does this antenna need a licence?
A: No. It is a passive antenna accessory and needs no licence. The host Meraki access point needs its own Meraki licence.

Q: Which Meraki access points does it work with?
A: It is for Meraki indoor access points with external antenna ports, including the MR42E and MR53E. The MR46E is also listed for the single-unit antennas.

Q: Does it need power?
A: No. It is a passive antenna with no power requirement. It draws signal from the access point through the RP-TNC connector.

Q: How does this differ from the other MA-ANT-3 versions?
A: This MA-ANT-3-A1 is a single antenna. The MA-ANT-3-A5 is a 5-pack and the MA-ANT-3-A6 is a 6-pack, and all share the same 3.8/5.5 dBi fixed dipole design.
