Juniper

Juniper QFX-QSFP-40G-SR4 | 40G QSFP+ 40GBASE-SR4 Transceiver, 850nm, MPO-12

SKU:QFX-QSFP-40G-SR4

$515.90 inc. GST
$469.00 ex. GST
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

Condition
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This Juniper 40GBASE-SR4 QSFP+ transceiver provides short-reach 40 Gigabit Ethernet over multimode fibre. It suits data centre links such as rack-to-rack and leaf-spine connections between Juniper switching platforms with 40GbE QSFP+ ports, including QFX and EX models.

The module transmits at 850nm over an MPO-12 connector using four parallel 10G lanes. Reach is 100 m on OM3 multimode fibre and 150 m on OM4. Digital optical monitoring is supported, and the module is hot-pluggable. It operates from 0 to 70 C and is not breakout capable, so it is intended for 40G to 40G links rather than splitting into 4x 10G.

It requires MPO-12 multimode fibre, OM3 or OM4. Check the Juniper Hardware Compatibility Tool to confirm support for your exact platform and Junos release.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- 40GBASE-SR4 over multimode fibre using 4 parallel lanes (4 x 10G)
- MPO-12 optical connector
- Digital optical monitoring (DOM) supported
- Hot-pluggable QSFP+ form factor
- Reach of 100 m on OM3 and 150 m on OM4 fibre
- Powered by the host switch port, no external supply needed

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

Also Known As

FAQs

Technical Specifications

- Speed: 40 Gigabit Ethernet
- Standard: 40GBASE-SR4
- Form factor: QSFP+
- Wavelength: 850nm
- Connector: MPO-12
- Reach: 100 m on OM3 / 150 m on OM4 multimode fibre
- Digital optical monitoring: Yes
- Breakout capable: No
- Maximum power consumption: 3.5 W
- Operating temperature: 0 to 70 C
- Storage temperature: -40 to 85 C
- Part number: 740-067442
- Old part number: 740-032986

Also Known As

740-067442, 740-032986

FAQs

Q: What fibre does this transceiver need?
A: It needs MPO-12 multimode fibre. Reach is 100 m over OM3 and 150 m over OM4.

Q: Which Juniper platforms does it work with?
A: It is used in Juniper switching platforms with 40GbE QSFP+ ports, such as QFX and EX models. Confirm your exact platform and Junos release in the Juniper Hardware Compatibility Tool.

Q: Can it be used as a 4x 10G breakout?
A: No. This module is not breakout capable and is designed for 40G to 40G links.

Q: Does it support digital optical monitoring?
A: Yes. It supports digital optical monitoring so you can read optical power and temperature from the host switch.

Q: How much power does it draw?
A: The listed maximum power consumption is 3.5 W, drawn from the host switch port.
