Juniper MPC4E-3D-2CGE-8XGE-IRB | MX MPC4E 2x100GbE + 8x10GbE Line Card, IRB, 16 L3VPNs

MPC4E-3D-2CGE-8XGE-IRB

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The MPC4E-3D-2CGE-8XGE-IRB is a fixed-configuration Trio-based line card for Juniper MX Series 3D Universal Edge Routers. It suits service-provider and enterprise edge, aggregation and core deployments that need high-density 100GbE and 10GbE with L2 and L3 services, including IP/MPLS edge, L3VPN, VPLS, mobile backhaul and business or residential Ethernet services.

The card provides two 100GbE CFP ports and eight 10GbE SFP+ ports, with up to 260 Gbps of line-rate throughput. The IRB bundle includes the full-scale L2/L2.5 and L3 feature licence, limited to up to 16 L3VPNs per MPC, which is what separates it from the -RB variant with full L3VPN scale. Worst-case power draw is 610 W (12.7 A at 48 V), although actual draw is typically much lower.

The card is supported in MX240, MX480, MX960, MX2010 and MX2020 chassis and runs Junos OS 12.3R2 or later. It requires SCBE switch fabric and high-capacity power supplies and fan trays. It is backward compatible with existing MX Series DPCs and Trio-based MPCs.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Powered by the Junos Trio chipset with a Dynamic Policy Engine for QoS
- L2 and L3 Ethernet services on a single card: 802.1Q VLAN, link aggregation, CCC, VRRP, VPLS and BGP/MPLS VPNs
- Hierarchical, class-aware rate limiters and dynamic bandwidth profiles
- Transport-class network timing (G.8261/G.8262/G.8264) for mobile backhaul and TDM migration
- Configurable LAN-PHY or WAN-PHY mode per 10GbE port
- Optical diagnostics and alarms with intelligent oversubscription
- Backward compatible with existing MX Series DPCs and Trio-based MPCs, SCBE fabrics, power supplies and fans
- Can interoperate with 100GbE PICs on Type 4 FPC

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Ports: 2 x 100-Gigabit Ethernet (CFP) + 8 x 10-Gigabit Ethernet (SFP+)
- Line-rate throughput: up to 260 Gbps
- Licensing: full-scale L2/L2.5 and L3 features (IRB bundle)
- L3VPN scale: up to 16 L3VPNs per MPC
- Base card model: MPC4E-3D-2CGE-8XGE
- Power requirement: 12.7 A @ 48 V (610 W) worst case
- Dimensions (H x W x D): 1.25 in x 17 in x 22 in (3.2 x 43.2 x 55.9 cm)
- Weight: 19.4 lb (8.8 kg)
- Operating temperature: 0 to 40 C (32 to 104 F)
- Storage temperature: -40 to 70 C (-40 to 158 F)
- Relative humidity (operating): 5% to 90% non-condensing
- Minimum Junos OS release: 12.3R2 and later
- Maximum MTU for host-bound packets: 9,192 bytes (9,500 bytes on Junos 16.1R1 and later)
- WAN-PHY mode: 10 Gbps, per-port basis
- Supported 100GbE optics: CFP 100GBASE-LR4, 100GBASE-SR10
- Supported 10GbE optics: SFP+ 10GBASE-LR, SR, ER, ZR
- Max 10GbE ports per chassis: MX2020 640, MX2010 320, MX960 320, MX480 160, MX240 96
- Max 100GbE ports per chassis: MX2020 40, MX2010 20, MX960 20, MX480 10, MX240 6
- LEDs: one bicolour OK/FAIL LED, one tricolour LINK LED per port
- Compliance: NEBS GR-63-Core, GR-1089-Core, SR-3580 Level 3 (with exceptions), AS/NZS CISPR22:2009, FCC Class A, EN 55022 Class A

FAQs

Q: What does the IRB suffix mean on this line card?
A: The -IRB suffix denotes the bundle that includes the full-scale L2/L2.5 and L3 feature licence, limited to up to 16 L3VPNs per MPC. The -RB variant adds full L3VPN scale.

Q: Which MX chassis support the MPC4E-3D-2CGE-8XGE-IRB?
A: It is supported on the MX240, MX480, MX960, MX2010 and MX2020. It is not supported on the MX204. It requires SCBE switch fabric and high-capacity power supplies and fan trays.

Q: Which optics does it use?
A: The two 100GbE ports take CFP 100GBASE-LR4 or 100GBASE-SR10 optics. The eight 10GbE ports take SFP+ 10GBASE-LR, SR, ER or ZR optics.

Q: What power does the card need?
A: It draws power from the 48 V DC backplane, with a worst case of 610 W (12.7 A at 48 V). Actual draw is much lower, but high-capacity power supplies and fan trays are required.

Q: Are there slot restrictions in the chassis?
A: Yes. By default only 5 of 6 slots on an MX480 and 10 of 11 slots on an MX960 can be populated with MPC4E cards. Setting the ambient temperature to 25 or 40 C allows all slots to be populated.

Q: Which Junos OS release does it require?
A: Junos OS 12.3R2 or later is required.
