Juniper MIC-3D-16CHE1-T1-CE | MX 16-Port Channelized E1/T1 CE MIC, DS0, RJ-48C

MIC-3D-16CHE1-T1-CE

Stock Status: Enquire

Request Quote
Sale Sold out
Shipping calculated at checkout.
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The MIC-3D-16CHE1-T1-CE is a 16-port channelized E1/T1 circuit emulation Modular Interface Card for Juniper MX Series routers. It suits networks that still carry legacy TDM services and need to aggregate them over packet or MPLS infrastructure using pseudowires.

Each of the 16 RJ-48C ports can be set to either E1 or T1 and channelized down to DS0, giving 24 DS0 channels per T1 and 32 DS0 channels per E1. Circuit emulation is handled with SAToP and CESoPSN, built on PWE3 pseudowire encapsulations. Clocking can be internal or loop, T1 framing supports SF, ESF and D4/superframe, and E1 framing supports G704, G704-no-crc4 and unframed. The card draws 26.55 W (2.21 A at 12 V) from the host chassis and needs Junos OS 12.3 or later. This is the non-hardened version, the environmentally hardened variant is the -H model.

The MIC is supported on MX240, MX480 and MX960 routers from Junos 12.3, MX2008 from 15.1F7, and MX2010 and MX2020 from 13.2R2, installed through compatible MPCs.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Sixteen E1 or T1 ports, selectable per port
- Channelization down to DS0 for fine-grained TDM service delivery
- SAToP (RFC 4553) and CESoPSN (RFC 5086) TDM circuit emulation
- PWE3 pseudowire encapsulations (RFC 3985, RFC 3916, RFC 4385)
- Full bit error rate test (BERT) with local, remote and per-port loopback diagnostics
- In-service software upgrade (Unified ISSU)
- Internal and loop clocking options

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Module type: MIC
- Ports: 16 x E1/T1 (selectable E1 or T1 per port), RJ-48C
- DS1 channelization per port: 1 DS1 channel, 24 DS0 channels
- E1 channelization per port: 1 E1 channel, 32 DS0 channels
- Circuit emulation: SAToP, CESoPSN, PWE3
- Clocking: Internal and loop clocking
- Framing (T1): SF, ESF, D4/superframe
- Framing (E1): G704, G704-no-crc4, unframed
- Software release: Junos OS 12.3 and later
- Power requirement: 2.21 A @ 12 V (26.55 W maximum)
- Weight: 1.57 lb (0.71 kg)
- Diagnostics: Full BERT, local, remote and per-port loopback
- Unified ISSU: Supported

FAQs

Q: Does this MIC need a separate licence?
A: No separate licence for the MIC itself is stated in the manufacturer documentation. It requires Junos OS 12.3 or later on the host MX router.

Q: Which MX Series routers support this MIC?
A: It is supported on MX240, MX480 and MX960 from Junos 12.3, MX2008 from Junos 15.1F7, and MX2010 and MX2020 from Junos 13.2R2, installed via compatible MPCs. Check the Juniper MIC/MPC compatibility table for your chassis and MPC.

Q: How much power does the MIC draw?
A: It has a maximum power requirement of 26.55 W (2.21 A at 12 V), drawn from the host MX chassis.

Q: Can the ports be set to E1 or T1?
A: Yes. Each of the 16 ports is selectable as E1 or T1. Framing is configured per MIC, not per port.

Q: How does this differ from the -H version?
A: MIC-3D-16CHE1-T1-CE is the standard non-hardened card. The environmentally hardened variant is sold as MIC-3D-16CHE1-T1-CE-H.
