Juniper MIC-3D-16CHE1-T1-CE-H | MX Series 16-Port E1/T1 Circuit Emulation MIC, H Variant

SKU:MIC-3D-16CHE1-T1-CE-H

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

The MIC-3D-16CHE1-T1-CE-H is a channelized E1/T1 circuit emulation Modular Interface Card for Juniper MX Series routers. It is the H variant of the MIC-3D-16CHE1-T1-CE and is aimed at service providers and enterprises that need to carry legacy TDM services over packet networks, including T1/E1 service aggregation using CESoPSN and SAToP circuit emulation.

The card provides 16 E1/T1 ports with per-MIC E1/T1 framing and per-port operation. Each T1 port supports 1 DS1 channel or 24 DS0 channels, and each E1 port supports 1 E1 channel or 32 DS0 channels. Internal and loop clocking are both available. A single OK/FAIL status LED indicates module state.

The MIC draws up to 26.55 W (2.21 A at 12 V) from the host chassis and has no separate power supply. It weighs 0.71 kg and is rated for operation from -40 to 65 C. It requires Junos OS 13.2R2 or later and installs in MPC slots on MX Series routers. Check the Juniper Hardware Compatibility Tool for your chassis and MPC before ordering.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Sixteen E1 or T1 ports on a single MIC
- Per-port selectable E1 or T1 operation
- DS0-level channelization with 24 DS0 for T1 and 32 DS0 for E1
- Internal and loop clocking options
- OK/FAIL status LED
- Circuit emulation for carrying TDM services over packet networks

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Module type: Modular Interface Card (MIC)
- E1/T1 port count: 16
- Framing: Per-MIC E1/T1 framing
- DS1 channelization per port: 1 DS1 channel or 24 DS0 channels
- E1 channelization per port: 1 E1 channel or 32 DS0 channels
- Clocking: Internal and loop clocking
- Power requirement: 2.21 A at 12 V
- Maximum power consumption: 26.55 W
- Weight: 1.57 lb (0.71 kg)
- Operating temperature: -40 to 65 C (-40 to 149 F)
- Minimum Junos OS release: 13.2R2 and later

FAQs

Q: Which software release does this MIC require?
A: It requires Junos OS 13.2R2 or later.

Q: Does this MIC need its own power supply?
A: No. It draws up to 26.55 W (2.21 A at 12 V) from the host MX Series chassis.

Q: Which MX platforms support the H variant?
A: Juniper's MIC/MPC compatibility tables list the (H) variant with 13.2R2 support on the MX2020. Check the Juniper Hardware Compatibility Tool for your chassis and MPC before ordering.

Q: How does the H variant differ from MIC-3D-16CHE1-T1-CE?
A: The H variant has its own platform support listing in Juniper's compatibility tables, so confirm your chassis and MPC against them. The 16-port E1/T1 circuit emulation function is the same.

Q: What traffic is this MIC designed for?
A: It carries TDM services such as legacy T1/E1 circuits over packet networks using circuit emulation (CESoPSN and SAToP).
