HPE P39171-B21 | DL325 Gen10 Plus v2 | 2SFF NVMe Tri-Mode PCIe | Backplane-to-PCIe controller cabling

SKU:P39171-B21

Regular price POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

Dedicated internal cabling to link a 2x SFF tri-mode backplane to a PCIe slot-based tri-mode controller in DL325 Gen10 Plus v2 systems. Designed for SAS/SATA/NVMe flexibility with proper lane mapping and signal integrity from backplane to controller. Controller and backplane not included.

Features

- Backplane-to-PCIe controller harness for 2 SFF bays
- Tri-mode ready: SAS, SATA, and NVMe
- Optimized for DL325 Gen10 Plus v2 internal topology
- Maintains high-speed signal integrity for NVMe Gen4
- Simplifies controller upgrades and migrations
- Factory-style labeling and fitment for easier service
- Reduces downtime versus sourcing mismatched cables

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details
  • You may also like
  • Best sellers
  • Related Products

specs-tabs

Collapsible content

FAQs

Technical Specifications

FAQs

Q: Which controllers are supported?
A: Tri-mode Smart Array PCIe add-in controllers from the SR family are typically supported. Check your controller’s quickspecs for this server.

Q: Can I use this without a controller?
A: No. This kit is intended to connect the backplane to a PCIe slot-based tri-mode controller.

Q: Is the cable length correct for the DL325 chassis?
A: Yes. The harness is designed for the DL325 Gen10 Plus v2 internal layout and routing.

Q: Does it support NVMe performance?
A: Yes, when paired with a tri-mode controller and NVMe-capable backplane, it supports NVMe over PCIe (up to Gen4 where applicable).

Q: Are drive carriers or backplanes included?
A: No. Only the internal cable kit is included.

Technical Specifications

- Platform compatibility: DL325 Gen10 Plus v2
- Supported drive bays: 2x SFF tri-mode (SAS/SATA/NVMe)
- Cabling type: Internal backplane-to-PCIe controller
- Protocols supported: NVMe over PCIe, SAS, SATA (tri-mode)
- Controller type: PCIe add-in tri-mode RAID/HBA (Smart Array SR family)
- Performance: PCIe Gen4 NVMe and up to 12Gb SAS (where supported)
- Use case: Connect 2-bay tri-mode backplane to discrete controller
- Kit contents: Internal cable harness set (no controller/backplane)
- Routing: Factory-length, chassis-appropriate pathing
- Note: Ensure controller and backplane are tri-mode compatible
