HPE P39168-B21 | DL325 Gen10 Plus v2 | 2SFF NVMe Tri-Mode | SAS/SATA/NVMe backplane cabling

SKU:P39168-B21

Regular price POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

Internal tri-mode cabling set for DL325 Gen10 Plus v2 2x SFF bays, providing the correct connections for a tri-mode backplane supporting SAS, SATA, and NVMe. Ideal when deploying mixed-media or transitioning between protocols, ensuring controller-to-backplane compatibility and signal integrity. Does not include backplane or controller hardware.

Features

- Enables tri-mode operation (SAS/SATA/NVMe) for 2 SFF bays
- Purpose-built harnessing ensures reliable signal integrity
- Compatible with Smart Array Tri-Mode controllers (model dependent)
- Supports PCIe Gen4 NVMe and up to 12Gb SAS where applicable
- Factory-style routing for clean installs and serviceability
- Ideal for mixed-media storage strategies
- Reduces errors from mismatched or generic cabling

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details
  • You may also like
  • Best sellers
  • Related Products

specs-tabs

Collapsible content

FAQs

Technical Specifications

FAQs

Q: Will this work with NVMe-only or SAS-only setups?
A: Yes. Tri-mode cabling supports NVMe and SAS/SATA when paired with a tri-mode capable controller and backplane.

Q: Does the kit include a RAID controller?
A: No. It provides only the internal cabling needed to connect your existing tri-mode controller to the 2SFF backplane.

Q: Can I mix SAS and NVMe drives in the same cage?
A: Tri-mode backplanes and controllers allow per-bay protocol flexibility, but mixing rules vary by backplane and firmware. Check your server documentation.

Q: Is firmware configuration required after installation?
A: In most cases you should verify controller and backplane firmware, and confirm drive detection in system setup after cabling.

Q: Does this fit DL325 Gen10 Plus (non v2)?
A: It is intended for DL325 Gen10 Plus v2. Confirm mechanical and electrical compatibility for other revisions before purchase.

Technical Specifications

- Platform compatibility: DL325 Gen10 Plus v2
- Supported drive bays: 2x SFF (tri-mode capable)
- Cabling type: Internal tri-mode (SAS/SATA/NVMe)
- Protocols supported: SAS, SATA, NVMe (tri-mode backplane/controller dependent)
- Controller compatibility: Smart Array Tri-Mode series (e.g., SR family)
- Connection path: Tri-mode backplane to controller/system as applicable
- Performance: PCIe Gen4 for NVMe, 12Gb SAS for SAS (where supported)
- Use case: Mixed-media or flexible protocol deployments
- Kit contents: Internal cable harness set (no backplane/controller)
- Installation: Chassis-internal, factory-length routing
- Note: Verify backplane is tri-mode capable before use
