HPE

HPE P26431-B21 | DL360 Gen10 Plus 8SFF backplane | x1 Tri-Mode 24G U.3 | SAS/SATA/NVMe U.3 | hot-plug

P26431-B21

POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

Enable U.3 Tri‑Mode capability in an 8-bay SFF front cage with a single-link 24G U.3 backplane for DL360 Gen10 Plus. Ideal for boot and mixed-capacity tiers where a single U.3 link to a Tri‑Mode controller meets throughput needs while preserving SAS/SATA/NVMe flexibility.

Features

- Tri-Mode U.3 backplane for SAS, SATA, and NVMe flexibility
- Cost-effective single-link (x1) connectivity for moderate bandwidth needs
- Hot-plug SFF bays with intuitive LEDs
- Seamless mechanical fit for DL360 Gen10 Plus
- Simplifies upgrades to U.3 media without changing the chassis

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Technical Specifications

- Platform compatibility: ProLiant DL360 Gen10 Plus (1U)
- Front bay layout: 8x SFF (2.5-inch) hot-plug
- Backplane type: Tri-Mode 24G U.3 (SAS4 / SATA / NVMe)
- Controller connectivity: x1 U.3 link to Tri-Mode controller
- Supported drives: SAS up to 24G, SATA 6G, NVMe U.3 (PCIe Gen4)
- Use case: Balanced cost/complexity for boot or mixed workloads
- Indicators: Per-bay status/activity LEDs
- Requirements: Compatible Tri-Mode controller and appropriate cabling
- Kit contents: 8SFF U.3 backplane; platform-specific cabling as required

FAQs

Q: What is the difference between x1 and x4 U.3 versions?
A: x1 provides a single U.3 link to the controller for simpler or lower-bandwidth needs, while x4 offers higher aggregate bandwidth via four links.

Q: Can I use NVMe and SAS drives together?
A: Yes, Tri-Mode U.3 supports SAS, SATA, and NVMe concurrently with a compatible controller. Verify controller mixing rules.

Q: Is a controller included?
A: No. A Tri-Mode (SAS/SATA/NVMe) controller is required and sold separately.

Q: Do I need special drive carriers for U.3?
A: Use the correct SFF carriers for your chassis and drive type; carriers are typically model-specific and sold separately.

Q: Does this work on non-DL360 Gen10 Plus servers?
A: No. It is designed specifically for DL360 Gen10 Plus.
