HPE 873732-B21 | DL38X Gen10 Secondary SlimSAS Riser | 4x SlimSAS ports | Enables up to 8x NVMe U.2

SKU:873732-B21

Regular price POA
POA
POA
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

Secondary riser that exposes four SlimSAS connectors to support up to eight NVMe U.2 drives (via appropriate backplane and cabling). Ideal for scaling flash capacity and throughput in DL38X Gen10 servers without consuming standard PCIe adapter slots. Requires matching NVMe backplane and cable kits for proper operation.

Features

- Cost-effective enablement of up to eight NVMe U.2 drives
- Maximizes flash bandwidth using direct PCIe lane connectivity
- Frees standard PCIe slots for other adapters
- Validated fit and airflow for DL38X Gen10 chassis
- Modular growth path for performance storage tiers

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details
  • You may also like
  • Best sellers
  • Related Products

specs-tabs

Collapsible content

FAQs

Technical Specifications

FAQs

Q: Does this riser by itself add NVMe support?
A: It provides the physical SlimSAS ports; you also need the correct NVMe backplane and cables for the drives to be recognized.

Q: How many NVMe drives can it enable?
A: Up to 8x U.2 NVMe drives, typically two per SlimSAS port with the appropriate cabling and backplane.

Q: Can I mix NVMe and SAS/SATA in the same chassis?
A: Yes, many DL38X Gen10 configurations support mixed backplanes, but each backplane must match the drive type it connects (NVMe vs. SAS/SATA).

Q: Does this provide RAID for NVMe drives?
A: No. NVMe RAID functionality, if required, depends on platform features or additional controllers/software.

Q: Are special firmware or license features needed?
A: Keep system firmware current. Some features may require platform-specific licenses; consult your server documentation.

Technical Specifications

- Server Compatibility: DL38X Gen10 (e.g., DL380/DL385 Gen10), model-dependent
- Ports: 4x SlimSAS (for NVMe U.2 connectivity)
- Drive Enablement: Up to 8x NVMe U.2 drives (typically 2 drives per SlimSAS port with the correct harness)
- Interface: PCIe lanes routed to NVMe backplane (Gen3 platform)
- Placement: Secondary riser position
- Required Accessories: Matching NVMe/U.2 backplane and SlimSAS cable kits
- Use Cases: High-throughput databases, virtualization, caching tiers
