HPE 721064-B21 | BladeSystem c-Class 40G QSFP+ to 4x 10G SFP+ DAC, 3m
SKU:721064-B21
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This HPE BladeSystem c-Class splitter cable is a 3-metre passive direct attach copper (DAC) breakout cable. It carries a 40GbE QSFP+ connector on one end that fans out to four 10GbE SFP+ connectors, making it suited to short-reach, low-latency links between BladeSystem c-Class interconnect modules, switches and 10GbE adapters.
The cable is 3 m (9.84 ft) long and has a 100 ohm characteristic impedance. Each SFP+ fan-out leg has a 0.175 inch diameter. Power draw is minimal, with a maximum of 0.042 W at the QSFP+ end and 0.011 W at each SFP+ end. It is rated for an operating temperature of 0 to 70 C and up to 10,000 ft (3 km) altitude.
It is intended for HPE BladeSystem c-Class interconnect modules, switches and 10GbE adapters that have QSFP+ and SFP+ ports. Breaking one 40GbE port into four 10GbE links in a single cable reduces cabling complexity, power and cost compared with separate optical links.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Cost-effective 40GbE QSFP+ to 4 x 10GbE SFP+ fan-out in a single cable
- Low-latency performance inherent to direct attach copper designs
- Reduces cabling complexity, power and cost in BladeSystem c-Class setups
- Suited to short-reach in-rack links between interconnect modules, switches and 10GbE adapters
- Passive design with no external power required
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Type: 40G QSFP+ to 4 x 10G SFP+ breakout (splitter) cable
- Cable technology: Direct attach copper (DAC), passive
- Length: 3 m (9.84 ft)
- Weight: 1.62 lb, fully loaded with 1 QSFP+ and 4 SFP+ transceivers
- Operating temperature: 0 to 70 C (32 to 158 F)
- Operating relative humidity: 5% to 95%, noncondensing
- Storage temperature: -20 to 80 C (-4 to 176 F)
- Storage relative humidity: 5% to 95%, noncondensing
- Altitude: Up to 10,000 ft (3 km)
- Power: 0.042 W maximum at QSFP+ end, 0.011 W at each SFP+ end
- Cable characteristic impedance: 100 ohms
- Crosstalk between pairs: 26 dB max
- Time delay: 1.32 nsec/ft
- BER: 10^-15 max
- Cable diameter: 0.175 inch for each SFP+ fan-out cable
- Minimum bend radius, SFP+ end: 0.7 inch
- Minimum bend radius, QSFP+ end: 1.78 inch
FAQs
Q: Does this cable need a licence or external power?
A: No. It is a passive copper cable with no external power or licence requirement. Maximum power draw is 0.042 W at the QSFP+ end and 0.011 W at each SFP+ end.
Q: What does this cable connect?
A: It connects one 40GbE QSFP+ port to four 10GbE SFP+ ports. It is intended for HPE BladeSystem c-Class interconnect modules, switches and 10GbE adapters with QSFP+ and SFP+ ports.
Q: How does this 3m cable differ from other lengths?
A: This SKU is the 3 m (9.84 ft) version of the 40G QSFP+ to 4x 10G SFP+ splitter cable. Choose the length that suits the distance between your devices.
Q: Can it be used for longer links between racks?
A: It is designed for short-reach, in-rack links. For longer distances, consider optical transceivers and fibre cabling instead.
