HPE 655874-B21 | QSFP+ to SFP+ Adapter, 40G Port to 10G, QSA

SKU:655874-B21

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This QSFP+ to SFP+ adapter, also known as a QSA, fits into a 40GbE QSFP+ port and lets that port accept a single SFP+ (10GbE) or SFP (1GbE) transceiver, DAC or AOC. It suits mixed-speed and migration environments where a 40GbE QSFP+ server or switch port needs to connect to existing 10GbE or 1GbE optics and cables, for example the 10GbE connection on the ProLiant SL4540 Gen8 QSFP port.

The adapter presents one SFP+/SFP receptacle on the module side and a QSFP+ interface on the host side. The SFP channel is wired to QSFP+ lane 1, giving a single 10GbE lane, while the other three lanes are not connected. It is a passive device drawing a maximum of 0.1 W from the host port at a 3.3 V nominal supply, with an operating case temperature of 0 to 70 C. The design follows the QSFP+ MSA SFF-8436 and SFP+ MSA SFF-8418/8419 standards and is RoHS compliant.

It works with HPE SFP+ transceivers and DAC or AOC cables on the SFP side. Support is specific to the port and platform, so confirm that your QSFP+ port supports this adapter before ordering.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Lets a 40GbE QSFP+ port accept a single SFP+ or SFP transceiver, DAC or AOC
- Vendor-agnostic design with direct access to the SFP module's memory
- Low insertion loss and matched impedance on the conversion path
- Secure latching mechanism
- Connects a switch QSFP+ port to a NIC SFP port, or a NIC QSFP+ port to a switch SFP port
- Qualified for 10GbE SFP+ and 1GbE SFP modules

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Host interface: QSFP+
- Module interface: 1 x SFP+/SFP receptacle
- Port speed conversion: 40Gb/s QSFP+ port to 10GbE SFP+ (single lane)
- Supported modules: 10GbE SFP+ and 1GbE SFP
- Lane mapping: SFP channel connected to QSFP+ lane 1, other three lanes not connected
- Standards: QSFP+ MSA SFF-8436, SFP+ MSA SFF-8418/8419
- Management interface: SFF-8636 compliant I2C interface for reading the SFP transceiver
- Supply voltage (Vcc): 3.135 / 3.3 / 3.465 V (min/typ/max)
- Power consumption: 0.1 W max
- Operating case temperature: 0 to 70 C
- Operating relative humidity: 5 to 85 %
- Storage temperature: -40 to 85 C
- Characteristic impedance: 90 / 100 / 110 ohm (min/typ/max)
- Absolute max supply voltage: -0.3 to 3.6 V
- Compliance: RoHS
- OEM part number: MAM1Q00A-QSA
- HPE spare part number: 655902-001

FAQs

Q: Does this adapter need external power?
A: No. It is a passive adapter powered from the host port at a 3.3 V nominal supply, with a maximum consumption of 0.1 W.

Q: Which modules can I use in the SFP side?
A: It accepts a single 10GbE SFP+ or 1GbE SFP transceiver, DAC or AOC. It works with HPE SFP+ transceivers and DAC or AOC cables.

Q: Will it give me 40G speeds?
A: No. It converts one QSFP+ lane to a single SFP+ port, so you get 10GbE. The other three QSFP+ lanes are not connected.

Q: Which HPE platforms is it intended for?
A: It is listed for the HPE ProLiant SL4540 Gen8, where 10GbE on the QSFP port requires this adapter. Support is port and platform specific, and some switches such as the Aruba 8320 do not support it.

Q: Can I connect a switch QSFP+ port to a server SFP port with it?
A: Yes. It can connect a switch QSFP+ port to a NIC SFP port, or a NIC QSFP+ port to a switch SFP port, provided both ends support the adapter.
