HPE 537963-B21 | BladeSystem c-Class 10G SFP+ DAC Cable, 5m Copper
SKU:537963-B21
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This is a 10GbE SFP+ to SFP+ direct attach copper cable in the HPE BladeSystem c-Class range. It has SFP+ connectors permanently attached at each end, which makes it a low-cost alternative to optical links for short-range data centre connections between switches, servers and BladeSystem c-Class interconnects.
This 5m (16.40 ft) length is built for 10-GbE serial data transmission and is SFF-8431 compliant. It is a passive copper cable that needs no external power and draws just 0.04 W maximum, which helps keep power consumption and overall networking costs down. The cable has a 100 ohm characteristic impedance, a 0.180 inch diameter and a 1.0 inch minimum bend radius, and weighs 0.34 kg.
It is intended for HPE BladeSystem c-Class 10GbE SFP+ ports and other SFP+ ports. The 5m length suits runs between adjacent racks where a 1m or 3m cable would fall short.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- SFF-8431 compliant
- Supports 10-GbE data rate operation
- Serial data transmission
- SFP+ connectors permanently attached to each end of the cable
- Low-price alternative to optical links for short-range connections
- Reduces power consumption and overall networking costs
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Type: 10GbE SFP+ to SFP+ direct attach copper cable
- Length: 5 m (16.40 ft)
- Standards compliance: SFF-8431
- Data rate: 10-GbE, serial data transmission
- Power: 0.04 W maximum
- Cable characteristic impedance: 100 ohms
- Crosstalk between pairs: 2% max
- Time delay: 1.31 nsec/ft
- Cable diameter: 0.180 inch
- Minimum cable bend radius: 1.0 inch
- Weight: 0.34 kg (0.75 lb), including an SFP+ transceiver at each end
- Operating temperature: 0 to 70 C
- Operating relative humidity: 5% to 95%, noncondensing
- Storage temperature: -10 to 85 C
- Storage relative humidity: 5% to 95%, noncondensing
- Altitude: up to 3 km (10,000 ft)
FAQs
Q: Does this cable need external power?
A: No. It is a passive copper cable with no external power required, and it draws 0.04 W maximum.
Q: Which ports is it compatible with?
A: It is intended for HPE BladeSystem c-Class 10GbE SFP+ ports and other SFP+ ports. Operating system support follows the host server operating system support matrix.
Q: Can the SFP+ ends be removed?
A: No. The SFP+ connectors are permanently attached to each end of the cable, so it works as a complete link without separate optics.
Q: What other lengths are in this cable range?
A: The same HPE specification also covers 1m (487652-B21) and 3m (487655-B21) cables. This SKU is the 5m length.
Q: How far can this cable run?
A: This cable is 5m (16.40 ft) long and is designed for short-range 10GbE links within and between adjacent racks.
