CPAC-TR-40SR-QSFP300m-D-BCC | Checkpoint Compatible 40GB Multi-Mode 400m (40GBASE-CSR4)

CPAC-TR-40SR-QSFP300m-D-BCC

20 in stock

$212.30 AUD
$212.30 AUD
$212.30 AUD
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The CPAC-TR-40SR-QSFP300m-D-BCC is a drop-in compatible replacement for the Check Point CPAC-TR-40SR-QSFP300m-D. This QSFP+ transceiver operates as plug-and-play in Check Point security appliances with 40GbE QSFP+ ports. - Compliant with IEEE 802.3ba 40GBASE-SR4 and 40GBASE-CSR4 for extended multimode reach - QSFP+ form factor, 40Gb/s aggregate data rate over four 10Gb/s lanes at 850nm wavelength - 300 meters over OM3 multimode fiber, 400 meters over OM4 multimode fiber, using 12-fiber MPO-12 connector - Each 10Gb/s lane is IEEE 10GBASE-SR compliant, enabling 4x10G breakout mode to duplex fiber links - Digital Diagnostic Monitoring (DOM) support via I2C interface per QSFP+ MSA - Hot-swappable, fully compliant with QSFP+ MSA SFF-8436 specification

Features

• IEEE 802.3ba 40GBASE-SR4 and 40GBASE-CSR4 compliance guarantee drop-in interoperability with standards-compliant 40GbE interfaces while delivering extended multimode reach beyond standard SR4 transceivers
• Four independent 10.3125 Gb/s transmit and receive channels using 850nm VCSEL arrays over parallel ribbon fibre, each lane fully IEEE 10GBASE-SR compliant for 4x10G breakout to duplex links
• MPO-12 parallel fibre interface requires 12-fiber ribbon cable with female MPO/MTP connector; eight active fibres carry bidirectional 40Gb/s traffic with polarity Type A or Type B supported
• Extended optical budget enables 300m on OM3 (2000 MHz·km) or 400m on OM4 (4700 MHz·km) 50/125 µm laser-optimised multimode fibre without active components
• Real-time digital diagnostics via I2C expose temperature, supply voltage, TX bias current, TX output power, and RX input power per MSA memory map for proactive link health monitoring
• Hot-pluggable design allows field insertion and removal without powering down the host platform; QSFP+ MSA-compliant 38-pin edge connector ensures mechanical and electrical compatibility

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we’ll deliver a replacement part before you return the faulty item—minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: CPAC-TR-40SR-QSFP300m-D-BCC
Reference SKU: CPAC-TR-40SR-QSFP300m-D
Compatibility: Check Point compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: QSFP+
Data Rate: 40Gb/s (4 x 10Gb/s lanes)
Wavelength: 850nm
Fibre Type: Multi-Mode (OM3/OM4)
Connector Type: MPO-12 (12-fiber parallel)
DOM Support: Yes (Digital Diagnostic Monitoring)
Standards: IEEE 802.3ba 40GBASE-SR4, 40GBASE-CSR4, IEEE 802.3ae 10GBASE-SR (per lane), QSFP+ MSA SFF-8436
Max Reach: 300m over OM3, 400m over OM4 (per datasheet, subject to fibre and link conditions)
Operating Temperature: 0°C to +70°C (commercial)

FAQs

Q: Will this work in place of the Check Point CPAC-TR-40SR-QSFP300m-D?
A: Yes. The CPAC-TR-40SR-QSFP300m-D-BCC is 40GBASE-CSR4 compliant using the QSFP+ form factor and 40Gb/s data rate with 850nm wavelength. It is plug-and-play compatible with Check Point platforms that specify the CPAC-TR-40SR-QSFP300m-D, including 9700, 9800, 19200, 29000, MHO140, and MHO175 series appliances with QSFP+ 40GbE ports.

Q: Which Check Point platforms support this transceiver?
A: This transceiver is compatible with Check Point security appliances that include QSFP+ 40GbE ports and specify 40GBASE-CSR4 or 40GBASE-SR4 support. Confirmed models include 9700, 9800, 19200, 29000, MHO140, and MHO175 series. Verify your platform includes QSFP+ 40G interfaces and runs firmware that recognises 40GBASE-CSR4 or 40GBASE-SR4 optics.

Q: What fibre type and cable do I need for 400m reach?
A: To achieve 400m reach you must use OM4 50/125 µm laser-optimised multimode fibre with a minimum 4700 MHz·km modal bandwidth. A 12-fiber MPO/MTP ribbon cable with female MPO-12 connectors on both ends is required. OM3 fibre limits reach to 300m. Cable polarity must be Type A or Type B to align transmit and receive lanes correctly across the link.

Q: Can I use this transceiver in 4x10G breakout mode?
A: Yes. Each of the four 10.3125 Gb/s lanes is IEEE 10GBASE-SR compliant, allowing you to connect this transceiver to four separate 10GBASE-SR interfaces using an MPO-12 to 4x duplex LC breakout cable. Each 10G lane will reach 100m on OM3 or 150m on OM4. The host switch must support QSFP+ 4x10G breakout configuration and lane mapping.

Q: How does 40GBASE-CSR4 differ from 40GBASE-SR4 in practical deployment?
A: Both use the same IEEE 802.3ba 40GBASE-SR4 foundation with four parallel 10Gb/s lanes at 850nm over MPO-12 multimode fibre. CSR4 is an extended-reach variant with higher optical budget, delivering 300m on OM3 and 400m on OM4, compared to SR4's 100m on OM3 and 150m on OM4. CSR4 and SR4 modules are interoperable, but the link distance is limited by the shorter-reach module.
