CPAC-TR-40SR-QSFP100m-D-BCC | Checkpoint Compatible 40GB Multi-Mode 150m (40GBASE-SR4)

CPAC-TR-40SR-QSFP100m-D-BCC

18 in stock

$212.30 AUD
$212.30 AUD
$212.30 AUD
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The CPAC-TR-40SR-QSFP100m-D-BCC is a drop-in compatible replacement for the Checkpoint CPAC-TR-40SR-QSFP100m-D. This QSFP+ transceiver provides plug-and-play 40 Gigabit Ethernet connectivity in Checkpoint security appliances with QSFP+ ports. - IEEE 802.3ba 40GBASE-SR4 compliance guarantees interoperability with all standard 40GbE SR4 interfaces - QSFP+ form factor with 4-lane parallel optics, 850nm VCSEL transmitter, MPO-12 connector - Supports 100m over OM3 multi-mode fibre and 150m over OM4 or OM5 multi-mode fibre - Digital optical monitoring (DOM) support via I2C interface for real-time parameter access - Hot-swappable design with commercial temperature range (0 to 70 degrees C) operation - QSFP+ MSA SFF-8436 compliant for mechanical and electrical compatibility

Features

• IEEE 802.3ba 40GBASE-SR4 standard compliance ensures this module operates seamlessly with any vendor's 40GbE SR4 port, including mixed-vendor topologies where Checkpoint appliances connect to Cisco, Juniper, or Arista switches
• Four independent 10 Gbps parallel optical lanes transported over 12-fibre ribbon cable provide inherent redundancy and enable 40G to 4x10G breakout connectivity when used with MPO-to-LC breakout cables
• 850nm VCSEL laser technology optimized for laser-optimized multi-mode fibre delivers low power consumption under 1.5W and supports both OM3 and OM4/OM5 fibre types with reach scaling to fibre grade
• Hot-swappable QSFP+ form factor allows installation and removal without powering down the appliance, critical for maintaining uptime during transceiver replacement or network reconfiguration
• Digital optical monitoring exposes transmit power, receive power, temperature, voltage, and bias current via I2C per QSFP+ MSA SFF-8436, enabling proactive link health monitoring and troubleshooting
• MPO-12 multifibre push-on connector uses keyed female interface ensuring correct polarity alignment with standard 12-fibre OM3 or OM4 trunk cables in structured cabling deployments

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we’ll deliver a replacement part before you return the faulty item—minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: CPAC-TR-40SR-QSFP100m-D-BCC
Reference SKU: CPAC-TR-40SR-QSFP100m-D
Compatibility: Checkpoint compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: QSFP+
Data Rate: 40 Gbps (4 x 10 Gbps lanes)
Wavelength: 850nm (840-860nm range)
Fibre Type: Multi-mode (OM3/OM4/OM5)
Connector Type: MPO-12 (MTP) female
DOM Support: Yes (digital diagnostics via I2C)
Standards: IEEE 802.3ba 40GBASE-SR4, QSFP+ MSA SFF-8436
Max Reach: 100m on OM3, 150m on OM4/OM5 (per datasheet, subject to fibre and link conditions)
Operating Temperature: 0 to 70 degrees C
Fibre Core: 50/125 micron multi-mode
Transmitter Type: 4-channel VCSEL array
Power Consumption: < 1.5W

FAQs

Q: Will this work in place of the Checkpoint CPAC-TR-40SR-QSFP100m-D?
A: Yes. This module is engineered to the same IEEE 802.3ba 40GBASE-SR4 and QSFP+ MSA SFF-8436 specifications as the Checkpoint original. It matches the QSFP+ form factor, 850nm wavelength, 40 Gbps data rate, and MPO-12 connector interface, ensuring plug-and-play operation in any Checkpoint appliance that specifies the CPAC-TR-40SR-QSFP100m-D.

Q: Which Checkpoint appliances support this transceiver?
A: This transceiver is compatible with Checkpoint 9700, 9800, 19200, and 29000 series security gateways, as well as Maestro MHO140 and MHO175 hyperscale orchestrators. Any Checkpoint appliance with a QSFP+ port rated for 40GbE that calls for the CPAC-TR-40SR-QSFP100m-D will accept this module.

Q: What is the actual reach difference between OM3 and OM4 fibre with this transceiver?
A: This module supports 100 metres over OM3 50/125 micron fibre and 150 metres over OM4 or OM5 50/125 micron fibre. The reach difference is driven by modal bandwidth: OM4 specifies 4700 MHz·km at 850nm versus OM3's 2000 MHz·km, allowing the four parallel 10 Gbps lanes to maintain signal integrity over the longer distance without exceeding the optical power budget.

Q: Can this transceiver be used with breakout cables to connect four separate 10GbE devices?
A: Yes, when paired with an MPO-12 to 4x duplex LC breakout cable. Each of the four 10 Gbps lanes can connect to an independent 10GBASE-SR SFP+ port. However, breakout mode requires host platform support: verify that your Checkpoint appliance firmware and interface module support 4x10G fanout configuration before deploying this topology.

Q: Does this module support operation in Checkpoint appliances with QSFP28 ports rated for 40/100G?
A: Yes, QSFP+ modules are mechanically and electrically compatible with QSFP28 ports when those ports are configured for 40GbE operation. The QSFP28 connector accepts QSFP+ form factor transceivers. Confirm the Checkpoint interface module or port is set to 40G mode rather than 100G mode, as this transceiver operates only at 40 Gbps aggregate rate across its four lanes.
