CPAC-TR-1T-D-BCC | Checkpoint Compatible 1GB Ethernet RJ45 100m (1000BASE-T)

CPAC-TR-1T-D-BCC

40 in stock

$66.00 AUD
$66.00 AUD
$66.00 AUD
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The CPAC-TR-1T-D-BCC is a drop-in compatible replacement for the Checkpoint CPAC-TR-1T-D. This SFP transceiver provides plug-and-play compatibility with Checkpoint security appliances equipped with SFP ports. - IEEE 802.3 and 802.3ab compliance guarantees interoperability with any 1000BASE-T network infrastructure - SFP form factor, 1.25 Gbps data rate, RJ45 connector for copper connectivity - Supports up to 100m transmission distance over Cat5, Cat5e, or Cat6 unshielded twisted pair cable - Operates over 10/100/1000 Mbps auto-negotiating copper links - Hot-swappable design for field installation without disrupting network operation - Commercial temperature range (0 to 70 degrees C) for standard networking environments

Features

• IEEE 802.3ab compliance ensures the transceiver negotiates link parameters automatically with any 1000BASE-T Ethernet switch or router port
• Built-in PHY chipset handles all copper signalling and auto-negotiation, removing protocol overhead from the host system
• 3.3V power interface draws typical 300 to 350 mA supply current, suitable for standard SFP power budgets in multi-port line cards
• SFP MSA mechanical and electrical compliance allows insertion into any standards-compliant SFP cage without physical or signal integrity issues
• Supports full duplex gigabit operation over four twisted pairs simultaneously using 4D-PAM5 encoding per 802.3ab
• Hot-swappable capability means the module can be installed or removed while the host device remains powered and operational
• RJ45 copper interface eliminates the need for media converters when connecting SFP ports directly to copper Ethernet infrastructure

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we’ll deliver a replacement part before you return the faulty item—minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: CPAC-TR-1T-D-BCC
Reference SKU: CPAC-TR-1T-D
Compatibility: Checkpoint compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: SFP
Data Rate: 1.25 Gbps
Standards: IEEE 802.3, IEEE 802.3ab, 1000BASE-T
Connector Type: RJ45
Cable Type: Cat5, Cat5e, Cat6 unshielded twisted pair (UTP)
Max Reach: 100m
Supported Speeds: 10/100/1000 Mbps auto-negotiation
Operating Temperature: 0 to 70 degrees C (commercial)

FAQs

Q: Will this work in place of the Checkpoint CPAC-TR-1T-D?
A: Yes. This transceiver is engineered to match the CPAC-TR-1T-D specification: SFP form factor, 1000BASE-T standard, RJ45 connector, and 100m reach over Cat5 or better cable. It provides plug-and-play compatibility with Checkpoint security appliances.

Q: Which Checkpoint appliances support this transceiver?
A: This module is compatible with Checkpoint security appliances that provide SFP ports, including the 9000, 19000, 29000, and MHO140 series. It works in any SFP slot that accepts 1G copper transceivers and is paired with the CPAC-8-1/10F-D network interface card in those platforms.

Q: What cable categories are required for full 100m reach?
A: Cat5, Cat5e, or Cat6 unshielded twisted pair cable all support 100m transmission at 1000 Mbps. The transceiver auto-negotiates speed (10/100/1000 Mbps) based on link partner capability and cable quality. All four pairs must be intact and properly terminated for gigabit operation.

Q: Does this module support auto-negotiation across different speeds?
A: Yes. The integrated PHY supports IEEE 802.3 auto-negotiation across 10BASE-T, 100BASE-TX, and 1000BASE-T. The module will negotiate the highest common speed with the link partner and automatically configure duplex mode, eliminating manual speed configuration in most deployments.

Q: What is the power consumption compared to fibre SFP modules?
A: This copper transceiver draws 300 to 350 mA at 3.3V (approximately 1 to 1.2 watts), which is higher than most fibre SFP modules due to the active PHY circuitry required for 1000BASE-T signalling. Ensure your line card or switch power budget accommodates copper SFP power requirements when populating multiple ports.
