CPAC-TR-100LR-D-BCC | Checkpoint Compatible 100GB Single-Mode 10km (100GBASE-LR4)

CPAC-TR-100LR-D-BCC

12 in stock

$1,301.30 AUD
$1,301.30 AUD
$1,301.30 AUD
Sale Sold out
Taxes included. Shipping calculated at checkout.

Description

The CPAC-TR-100LR-D-BCC is a drop-in compatible replacement for the Checkpoint CPAC-TR-100LR-D. This QSFP28 transceiver operates as a plug-and-play solution in Checkpoint security appliances with 40/100G QSFP28 ports. - IEEE 802.3ba 100GBASE-LR4 compliance guarantees interoperability with any 100G LR4 port across vendors - QSFP28 form factor, 100 Gigabit Ethernet, single-mode fibre, duplex LC connector, 10km maximum reach - Four LAN-WDM wavelengths at 1295.56nm, 1300.05nm, 1304.58nm, and 1309.14nm multiplexed over a single fibre pair - DOM support via I2C interface per QSFP28 MSA for real-time monitoring of optical power, temperature, bias current, and voltage - Hot-swappable module designed for 0 to 70 degrees Celsius commercial temperature range - Compliant with QSFP28 MSA SFF-8665 and IEEE 802.3bm CAUI-4 electrical interface specifications

Features

• IEEE 802.3ba 100GBASE-LR4 compliance ensures interoperability across multi-vendor 100G infrastructure without port-level compatibility testing
• Four-lane LAN-WDM architecture at 25.78125 Gbps per channel with NRZ modulation delivers 103.125 Gbps aggregate over duplex single-mode fibre using a single LC pair
• 6.3 dB minimum link budget per IEEE 802.3ba supports 10km reach over OS2 G.652.D single-mode fibre with standard connector insertion loss
• Digital diagnostic monitoring via I2C interface per SFF-8636 provides real-time telemetry for optical transmit and receive power, temperature, laser bias current, and supply voltage
• Hot-swappable installation in any QSFP28 MSA-compliant cage without interrupting host system operation or requiring powered-down maintenance windows
• Commercial temperature rating of 0 to 70°C suits standard rack-mounted data centre and enterprise network environments
• Single 3.3V power supply with maximum power consumption under 3.5W typical for 100GBASE-LR4 QSFP28 modules

Warranty

5-Year Advanced Warranty on All Blue Cable Co® Products

Blue Cable Co® offers a comprehensive 5-Year Advanced Warranty on all our branded products. Our advanced warranty ensures fast, hassle-free replacements to keep your network running smoothly. If a fault occurs, we’ll deliver a replacement part before you return the faulty item—minimising downtime and giving you complete peace of mind.

Choose Blue Cable Co® for reliable, high-quality network components backed by industry-leading warranty support.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Technical Specifications

FAQs

Compatible SFP Selector

Technical Specifications

Brand: Blue Cable Co
BCC SKU: CPAC-TR-100LR-D-BCC
Reference SKU: CPAC-TR-100LR-D
Compatibility: Checkpoint compatible
Lab Testing: Tested in Sydney, Australia
Warranty: 5-year advanced hardware replacement (Blue Cable Co)
Form Factor: QSFP28
Data Rate: 103.125 Gbps (100 Gigabit Ethernet)
Standards: IEEE 802.3ba 100GBASE-LR4, IEEE 802.3bm CAUI-4, QSFP28 MSA SFF-8665
Wavelength: 1295.56nm, 1300.05nm, 1304.58nm, 1309.14nm (LAN-WDM)
Fibre Type: Single-Mode (SMF)
Connector Type: Duplex LC
Max Reach: Up to 10km (per datasheet, subject to fibre and link conditions)
DOM Support: Yes, per QSFP28 MSA
Operating Temperature: 0 to 70°C (commercial)

FAQs

Q: Will this work in place of the Checkpoint CPAC-TR-100LR-D?
A: Yes. This transceiver is built to the same IEEE 802.3ba 100GBASE-LR4 standard, uses the QSFP28 form factor, and delivers 100 Gigabit Ethernet at 103.125 Gbps over single-mode fibre to 10km. It operates as a plug-and-play replacement in Checkpoint appliances that specify the CPAC-TR-100LR-D.

Q: Which Checkpoint appliances support this transceiver?
A: This module is compatible with Checkpoint security appliances equipped with QSFP28 ports supporting 40/100G operation. Confirmed models from Checkpoint documentation include the 9700, 9800, 19200, and 29000 series, as well as 16200, 16600, 26000, 28000, 28600, and Quantum Lightspeed platforms. Any appliance with a QSFP28 port and 100GBASE-LR4 support will accept this module.

Q: What fibre type and grade are required for the full 10km reach?
A: This module requires OS2 single-mode fibre (G.652.D standard) with duplex LC connectors. The IEEE 802.3ba standard specifies a 6.3 dB link budget for 100GBASE-LR4, which supports 10km assuming typical fibre attenuation of 0.4 dB/km and standard connector losses. OM3 or OM4 multimode fibre will not work with this module.

Q: Does this module support OTU4 or only 100 Gigabit Ethernet?
A: This module is primarily designed for 100GBASE-LR4 Ethernet at 103.125 Gbps per IEEE 802.3ba. Some LAN-WDM QSFP28 modules on the same wavelength plan support dual-rate operation including OTU4 at 111.81 Gbps, but this depends on the chipset and EEPROM configuration. Confirm with your Checkpoint appliance documentation whether OTU4 or OTN client interfaces are supported on the target platform before deploying for non-Ethernet applications.

Q: Can I access DOM parameters to monitor link health in real time?
A: Yes. This transceiver provides digital diagnostic monitoring per the QSFP28 MSA SFF-8636 specification, accessible via the I2C interface. You can monitor transmit and receive optical power on all four wavelength lanes, module temperature, laser bias current, and supply voltage. Most Checkpoint Gaia management interfaces and SNMP implementations expose these parameters for real-time link diagnostics and threshold alarming.
