Cisco VEDGE-2000-PWR | vEdge 2000 AC Power Supply, Hot-Swappable, 1+1
SKU:VEDGE-2000-PWR
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This hot-swappable AC power supply unit is a spare or replacement PSU for the Cisco vEdge 2000 SD-WAN router. It suits branch, regional hub and data-centre WAN edge deployments where power redundancy matters, and it can be replaced without powering down the router.
The vEdge 2000 chassis takes two PSUs in a 1+1 active-active redundant arrangement, so a second unit keeps the router running if one supply needs attention. The AC input accepts 90-264 Vrms (100-240 V) at 47-63 Hz, which covers global mains standards. The complete vEdge 2000 system draws about 125 W typical and 285 W maximum, and it is built with a front-to-back airflow chassis and two hot-swappable fans.
The power supply itself needs no licence. It is intended for the vEdge 2000 AC router chassis (VEDGE-2000-AC-K9), and the router it powers operates under Cisco SD-WAN (Viptela) software licensing.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-swappable design lets the PSU be replaced without powering down the router
- Dual-PSU 1+1 active-active redundancy for high availability in the vEdge 2000
- Wide-range AC input (100-240 V, 47-63 Hz) suits deployments worldwide
- Installs in a front-to-back airflow chassis with hot-swappable fans
- Suited to branch, regional hub and data-centre WAN edge routers
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product type: AC power supply unit (PSU)
- Hot-swappable: Yes
- Redundancy: 1+1 active-active (two PSU bays in chassis)
- AC input voltage: 90-264 Vrms (100-240 V)
- AC input line frequency: 47-63 Hz
- Compatible chassis: VEDGE-2000-AC-K9 (vEdge 2000 AC router)
- vEdge 2000 system typical power consumption: 125 W
- vEdge 2000 system maximum power consumption: 285 W
- Chassis airflow: Front to back
- Chassis fans: 2, hot-swappable
- Chassis weight with two power supplies installed: 15 lb (6.8 kg)
- Operating temperature: 0 to 40 C at sea level
- Operating humidity: 10 to 85% RH
- Storage temperature: -40 to 70 C
FAQs
Q: Does this power supply need a licence?
A: No. The power supply itself needs no licence. The vEdge router it powers operates under Cisco SD-WAN (Viptela) software licensing.
Q: Which chassis does it work with?
A: It is the AC power supply for the Cisco vEdge 2000 router chassis, VEDGE-2000-AC-K9.
Q: What input power does it need?
A: It accepts AC input of 90-264 Vrms (100-240 V) at 47-63 Hz. The vEdge 2000 system draws about 125 W typical and 285 W maximum.
Q: Can I replace it while the router is running?
A: Yes. The PSU is hot-swappable, and the chassis holds two units in 1+1 active-active redundancy, so one can be replaced without taking the router offline.
