Cisco

Cisco UCSC-GPU-A10 | NVIDIA A10 24GB GDDR6 GPU, 150W Single-Slot Passive

SKU:UCSC-GPU-A10

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

 Trade supply only. Server & GPU quote requests need a company name, ABN and work email address. We do not quote Gmail, Outlook or Hotmail addresses, or supply for home use.

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Custom Built Servers

Need a different spec, quantity or configuration?

We build configured-to-order refurbished servers from Cisco, Dell, HPE, NVIDIA Lenovo and Supermicro. Tell us what you need and we'll come back with options within 24 hours.

Configure your server now →

Description

The NVIDIA A10 Tensor Core GPU is a GPU accelerator card for Cisco UCS C-Series servers, built on the NVIDIA Ampere architecture. It suits virtual workstations with NVIDIA RTX vWS, graphics and video acceleration, AI inference and mixed VDI and compute workloads in mainstream enterprise servers.

The card carries 24 GB of GDDR6 memory with 600 GB/s of memory bandwidth, 72 RT Cores and 31.2 TFLOPS of FP32 performance. It connects over PCIe Gen4 at 64 GB/s in a 1-slot full-height full-length form factor, with a 150 W maximum TDP drawn through a single PEX 8-pin connector. Cooling is passive, so it relies on server chassis airflow. This 150W, single-slot, passive variant is the Cisco UCSC-GPU-A10 part number.

The card itself needs no licence to operate. Use with NVIDIA vGPU requires separately purchased NVIDIA vGPU software licences, covering vPC/vApps, RTX vWS or AI Enterprise. In the Cisco UCS C240 M6 it is supported as a single-wide GPU, up to 5 per server, and it is also listed for the C245 M6 and C240 M7.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Built on the NVIDIA Ampere architecture with 2nd-gen RT Cores and 3rd-gen Tensor Cores
- 24 GB of GDDR6 memory with 600 GB/s of bandwidth for graphics and inference workloads
- PCIe Gen4 interface doubles the bandwidth of PCIe Gen3
- Supports NVIDIA vGPU software for virtual PCs, virtual apps and RTX virtual workstations
- Optional secure and measured boot with a hardware root of trust
- NEBS Level 3 ready for demanding deployment environments
- Single-slot passive design allows several cards per supported server

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- GPU memory: 24 GB GDDR6
- Memory bandwidth: 600 GB/s
- Interface: PCIe Gen4, 64 GB/s
- Form factor: 1-slot full-height full-length (FHFL)
- Maximum TDP: 150 W
- Cooling: Passive (requires system airflow)
- Power connector: PEX 8-pin
- RT Cores: 72
- FP32: 31.2 TFLOPS
- TF32 Tensor Core: 62.5 TFLOPS (125 TFLOPS with sparsity)
- BFLOAT16 Tensor Core: 125 TFLOPS (250 TFLOPS with sparsity)
- FP16 Tensor Core: 125 TFLOPS (250 TFLOPS with sparsity)
- INT8 Tensor Core: 250 TOPS (500 TOPS with sparsity)
- INT4 Tensor Core: 500 TOPS (1000 TOPS with sparsity)
- Video engines: 1 encoder, 2 decoders, plus AV1 decode
- vGPU software support: NVIDIA vPC/vApps, RTX vWS, AI Enterprise
- Secure and measured boot with hardware root of trust: Optional
- NEBS: Level 3 ready

FAQs

Q: Does the A10 need a licence to work?
A: No, the card itself needs no licence to operate. Virtual GPU use requires separately purchased NVIDIA vGPU software licences, such as vPC/vApps, RTX vWS or AI Enterprise.

Q: Which Cisco UCS servers support this GPU?
A: It is supported in the Cisco UCS C240 M6 as UCSC-GPU-A10, as a single-wide card with up to 5 GPUs and a minimum Cisco IMC and BIOS version of 4.2(2f). It is also listed in the C245 M6 and C240 M7 GPU installation guides.

Q: How is the card powered and cooled?
A: It draws up to 150 W through one PEX 8-pin power connector. Cooling is passive, so the server chassis must provide adequate airflow across the card.

Q: Are there ambient temperature limits in the C240 M6?
A: The C240 M6 guide recommends a maximum ambient temperature of 30 C for 24 SFF chassis and 28 C for 12 LFF chassis when this GPU is fitted.
