Cisco UCS-SFP-1WLR | 10G SFP+ Transceiver, 10GBASE-LR, SMF, 10km, LC
SKU:UCS-SFP-1WLR
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The UCS-SFP-1WLR is a Cisco 10GBASE-LR SFP+ optical transceiver for 10 Gigabit Ethernet over standard G.652 single-mode fibre. It is built for 10GbE uplinks and server-to-switch links, such as campus or data-centre interconnects and UCS fabric connectivity, where a reach of up to 10 km is needed.
The module transmits and receives at 1310 nm through a dual LC/PC connector, with a minimum cabling distance of 2 m under IEEE 802.3ae. Transmit power ranges from -8.2 dBm to 0.5 dBm and receive power from -14.4 dBm to 0.5 dBm. It draws 1 W maximum from the host SFP+ port and operates from 0 to 70 C. The form factor is compact at 8.5 x 13.4 x 56.5 mm and 75 g or less, with a blue bail latch identifying the LR optic type.
Cisco SFP+ modules are supported on many Cisco platforms, including Catalyst, Nexus, ASR, MDS and UCS switches. Not every platform supports every module, so check the Cisco 10 Gigabit Ethernet Transceiver Modules Compatibility Matrix for your host. Only patch cords with PC or UPC connectors are supported.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- 10GBASE-LR reach of 10 km on standard single-mode fibre
- Hot-pluggable SFP+ form factor
- Supported across a wide range of Cisco switches and routers, including UCS
- Blue bail latch identifies the LR optic type
- Compliant with IEEE 802.3 and the SFP+ MSA
- Class 1 laser safety
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Product type: 10GBASE-LR SFP+ module for SMF
- Data rate: 10 Gigabit Ethernet
- Wavelength: 1310 nm (transmit and receive range 1260 to 1355 nm)
- Cable type: SMF G.652
- Maximum cable distance: 10 km
- Minimum cabling distance: 2 m (IEEE 802.3ae)
- Connector: Dual LC/PC
- Maximum transmit power: 0.5 dBm
- Minimum transmit power: -8.2 dBm
- Maximum receive power: 0.5 dBm
- Minimum receive power: -14.4 dBm
- Power consumption: 1 W max
- Operating temperature: 0 to 70 C (32 to 158 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)
- Dimensions (H x W x D): 8.5 x 13.4 x 56.5 mm
- Weight: 75 g or less
- Bail latch colour: Blue
- Standards: IEEE 802.3 10-Gigabit Ethernet, SFP+ MSA SFF-8431
- Safety: Laser Class 1 (21CFR-1040, IEC60825-1)
FAQs
Q: What fibre does this transceiver use?
A: It is designed for standard G.652 single-mode fibre with dual LC/PC connectors. The maximum reach is 10 km and the minimum cabling distance is 2 m.
Q: Which Cisco platforms support it?
A: Cisco SFP+ modules are supported on many Cisco platforms, including Catalyst, Nexus, ASR, MDS and UCS switches. Not every platform supports every module, so check the Cisco 10 Gigabit Ethernet Transceiver Modules Compatibility Matrix for your host.
Q: Does it need a separate power supply?
A: No. It draws 1 W maximum from the host SFP+ port.
Q: Can I use APC patch cords with it?
A: No. Only patch cords with PC or UPC connectors are supported.
Q: How does it differ from a 10GBASE-SR module?
A: The 10GBASE-LR optic runs at 1310 nm over single-mode fibre for up to 10 km. An SR module is built for short-reach multimode fibre.
