Cisco

Cisco SFP-OC3-LR2 | OC-3/STM-1 SFP Transceiver, Single-Mode, 80km, LC

SKU:SFP-OC3-LR2

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This Cisco SFP-OC3-LR2 is a hot-swappable 155 Mbps OC-3/STM-1 long-reach SFP transceiver for single-mode fibre. It is built for long-haul Packet-over-SONET/SDH, TDM and ATM links on Cisco routers, where a single span needs to reach up to about 80 km.

The transmitter operates across the 1480 to 1580 nm range (1550 nm class) with a transmit power of 0 to -5 dBm and a receiver power range of -10 to -34 dBm. It uses a dual LC/PC connector, so patch cords must be PC or UPC types, as APC connectors are not supported. Digital optical monitoring reports optical output power, optical input power, temperature, laser bias current and supply voltage. The module is a compact 8.6 x 13.7 x 56.5 mm and has a case temperature range of -5 to 85 C.

It plugs into SFP-based POS, TDM and ATM interfaces on Cisco router products and draws power from the host SFP port. No licence or subscription is required. Check the host router or line card documentation for exact platform support.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Hot-swappable SFP optical interface
- Compatible with SONET/SDH and ATM standards
- Long-reach 80 km span over single-mode fibre
- Real-time digital diagnostic monitoring of optical power, temperature, laser bias current and supply voltage
- Extended case temperature range of -5 to 85 C
- Class 1 laser safety compliance
- Compact SFP form factor for high port density

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Product description: SFP OC-3/STM-1 Long-Reach (80 km)
- Data rate: OC-3/STM-1 (155 Mbps)
- Typical distance: 80 km
- Fibre type: Single-mode
- Transmitter wavelength range: 1480 to 1580 nm
- Transmit power range: 0 to -5 dBm
- Receiver power range: -10 to -34 dBm
- Optical path penalty: 1 dB
- Connector: Dual LC/PC (APC patch cords not supported)
- Digital optical monitoring: Supported
- Digital diagnostics: Optical output power, optical input power, temperature, laser bias current and supply voltage (SFF-8742 MSA)
- Operating case temperature range: -5 to 85 C (23 to 185 F)
- Storage temperature range: -5 to 85 C (23 to 185 F)
- Dimensions (H x W x D): 8.6 x 13.7 x 56.5 mm
- Laser safety: Class 1 per IEC60825-1 and CFR 21, Part 1040.01
- Optical standards: GR-253, ITU G.957, G.707

FAQs

Q: Does this transceiver need a licence or subscription?
A: No. The SFP-OC3-LR2 does not require any licence or subscription to operate.

Q: What patch cords can I use with it?
A: Use dual LC patch cords with PC or UPC connectors on single-mode fibre. APC connectors are not supported.

Q: What does it plug into?
A: It fits SFP-based POS, TDM and ATM interfaces on Cisco router products. Check the host router or line card documentation to confirm exact platform support.

Q: How is it powered?
A: It draws power from the host SFP port, so no separate power connection is needed.

Q: How does it differ from other OC-3/STM-1 SFPs?
A: This is the long-reach version, covering about 80 km over single-mode fibre with a 1480 to 1580 nm transmitter, suited to longer spans than shorter-reach OC-3/STM-1 optics.
