Cisco SFP-H10GB-CU4M | 10G SFP+ to SFP+ DAC Cable, 4m, Passive, 24/26AWG

SKU:SFP-H10GB-CU4M

$146.00 USD
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

Condition
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This Cisco 10GBASE-CU SFP+ direct attach cable is a 4 m twinax copper assembly with an SFP+ connector at each end. It is built for very short 10 Gigabit Ethernet links within a rack or across adjacent racks, such as top-of-rack switch to server connections or switch-to-switch links in data centres and wiring closets.

The cable is passive, using 24AWG or 26AWG twinax copper, and draws a maximum of 0.1 W from the host SFP+ port with no separate power supply. It has a green bail latch, a commercial operating temperature range of 0 to 70 C, and the cable jacket is UL #E116441 compliant. It follows the SFP+ MSA SFF-8431 specification for passive twinax cables and is ELV and RoHS compliant. No licence or subscription is required.

The SFP+ connectors are hot-swappable, so the cable can be installed or replaced without powering down the switch. It plugs into SFP+ ports on Cisco platforms including Catalyst 2960, 3560, 3750, 3850, 4500 and 4500-X, Nexus 2000, 3000, 4000 and 9000, ASR 1000 and 9000, and UCS switches. Check the platform transceiver compatibility matrix for the exact model and software release.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- SFP+ is the smallest 10G form factor, giving the greatest port density per chassis
- Hot-swappable, so it can be installed or replaced without powering down the switch
- Supports a pay-as-you-populate model for investment protection
- Cisco Quality ID lets the host platform identify that the module is Cisco certified and tested
- Cost-effective way to connect within racks and across adjacent racks
- Passive design draws power from the host port with no separate power supply

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Product type: SFP+ to SFP+ direct attach cable (DAC)
- Standard: 10GBASE-CU, SFP+ MSA SFF-8431
- Cable length: 4 m
- Cable type: Twinax copper, passive, 24AWG or 26AWG
- Bail latch colour: Green
- Power consumption: 0.1 W maximum
- Operating temperature range: 0 to 70 C (32 to 158 F)
- Storage temperature range: -40 to 85 C (-40 to 185 F)
- SFP+ connector dimensions (H x W x D): 8.5 x 13.4 x 56.5 mm
- SFP+ connector weight: 75 g or less
- Safety: Cable jacket UL #E116441 compliant
- Environmental: ELV and RoHS compliant

FAQs

Q: Does this cable need a licence or subscription?
A: No. It is a passive copper cable and requires no licence or subscription.

Q: Is this an active or passive cable?
A: It is a passive twinax assembly using 24AWG or 26AWG copper. It draws a maximum of 0.1 W from the host SFP+ port and has no separate power supply.

Q: Which Cisco platforms does it work with?
A: It plugs into SFP+ ports on platforms such as Catalyst 2960, 3560, 3750, 3850, 4500 and 4500-X, Nexus 2000, 3000, 4000 and 9000, ASR 1000 and 9000, and UCS switches. Check the platform transceiver compatibility matrix for the exact model and software release.

Q: How far can this cable run?
A: It is a fixed 4 m cable, intended for connections within a rack or across adjacent racks. Longer runs need a longer cable or an optical transceiver.

Q: Can it be hot-swapped?
A: Yes. The SFP+ connectors are hot-swappable, so the cable can be installed or replaced without powering down the switch.
