Cisco SFP-10G-SR-I | 10G SFP+ Transceiver, Industrial -40 to 85C, MMF 400m
SKU:SFP-10G-SR-I
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
The SFP-10G-SR-I is a multirate 10GBASE-SR SFP+ optical transceiver for multimode fibre, built for the industrial operating temperature range of -40 to 85 C. It suits 10 Gigabit Ethernet links in data centre, enterprise wiring closet and service provider transport applications, and the wider temperature rating makes it a fit for harsher or uncontrolled environments. CPRI support also makes it suitable for fronthaul links.
The module operates at 850 nm over a dual LC connector and supports 10GBASE-SR, 10GBASE-SW and OTU2/OTU2e rates, plus CPRI options 3, 4, 5, 6, 7, 7a and 8. Reach depends on the fibre: 26 m on FDDI 62.5 um, 300 m on OM3 and up to 400 m on OM4. Maximum power consumption is 1 W, drawn from the host SFP+ port, and digital optical monitoring is supported for diagnostics.
It plugs into SFP+ ports on supported Cisco switches and routers. It requires patch cords with PC or UPC LC connectors, as APC connectors are not supported, and it interoperates optically with 10GBASE-SR XENPAK, X2 and XFP interfaces on the same link.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Multirate operation covering 10GBASE-SR, 10GBASE-SW, OTU2/2e and CPRI options
- Industrial temperature rating of -40 to 85 C for harsher environments
- Smallest 10G form factor for the greatest port density per chassis
- Hot-swappable, so no need to power down the switch to install or replace
- Digital optical monitoring for link diagnostics
- Optical interoperability with 10GBASE XENPAK, X2 and XFP interfaces on the same link
- Cisco quality ID lets the host platform identify the module as certified and tested by Cisco
- Supports a pay-as-you-populate model for investment protection
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
Also Known As
FAQs
Technical Specifications
- Form factor: SFP+ (10 Gigabit Ethernet)
- Supported standards: 10GBASE-SR, 10GBASE-SW, OTU2/OTU2e
- CPRI data rate options: 3, 4, 5, 6, 7, 7a, 8
- Wavelength: 850 nm (840 to 860 nm)
- Cable type: Multimode fibre (MMF)
- Connector: Dual LC/PC (APC patch cords not supported)
- Reach, 62.5 um FDDI (160 MHzkm): 26 m
- Reach, 62.5 um OM1 (200 MHzkm): 33 m
- Reach, 50 um (400 MHzkm): 66 m
- Reach, 50 um OM2 (500 MHzkm): 82 m
- Reach, 50 um OM3 (2000 MHzkm): 300 m
- Reach, 50 um OM4 (4700 MHzkm): 400 m
- Reach, 50 um OM5 (4700 MHzkm): 400 m
- Minimum cabling distance: 2 m
- Transmit power: -7.3 dBm min, -1.2 dBm max
- Receive power: -9.9 dBm min, -1.0 dBm max
- Maximum power consumption: 1 W
- Operating temperature: -40 to 85 C (industrial)
- Storage temperature: -40 to 85 C
- Dimensions (H x W x D): 8.5 x 13.4 x 56.5 mm
- Weight: 75 g or less
- Bail latch colour: Beige
- Laser safety: Class 1 IEC60825-1
- Digital optical monitoring: Supported
- FCoE support: Yes
Also Known As
SFP-10G-SR-I=, SFP-10G-SR-I-RF
FAQs
Q: What fibre and reach does the SFP-10G-SR-I support?
A: It runs over multimode fibre at 850 nm. Reach is 300 m on OM3 and up to 400 m on OM4, with shorter distances on OM1 and OM2 fibre.
Q: What connector and patch cords does it need?
A: It uses a dual LC connector and needs patch cords with PC or UPC LC connectors. APC connectors are not supported.
Q: How does it differ from the standard SFP-10G-SR?
A: The SFP-10G-SR-I is rated for the industrial temperature range of -40 to 85 C, suiting harsher or uncontrolled environments, and adds multirate support including OTU2/2e and CPRI options.
Q: Does it need a separate power supply?
A: No. It is powered from the host SFP+ port and draws a maximum of 1 W.
Q: Which devices will it work with?
A: It fits SFP+ ports on supported Cisco switches and routers. Not every device supports every module, so check the Cisco Optics-to-Device Compatibility Matrix for your platform and software version.
