Cisco

Cisco SFP-10G-BXD-I | 10G SFP+ BiDi Transceiver, BX10-D, TX 1330nm/RX 1270nm

SKU:SFP-10G-BXD-I

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

Condition
20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This is a 10GBASE-BX10-D SFP+ bidirectional (BiDi) transceiver from the Cisco 10GBASE SFP+ module range. It carries 10 Gigabit Ethernet over a single strand of standard G.652 single-mode fibre up to 10 km, which suits sites where fibre is scarce or where halving the number of strands matters. The industrial temperature rating and CPRI support on Version -02 also make it suitable for harsh environments and mobile fronthaul links.

It is the downstream end of a BX10 pair, transmitting at 1330 nm and receiving at 1270 nm (1260 to 1280 nm). The transmit power range is -8.2 to 0.5 dBm, the receive power range is -14.4 to 0.5 dBm, and maximum power consumption is 1 W. It operates from -40 to 85 C and supports Digital Optical Monitoring (SFF-8472) for optical power, temperature, laser bias current and supply voltage. Links up to 15 km are supported as engineered links where channel insertion loss is below 6.2 dB.

The far end of the link must use an SFP-10G-BXU-I, which transmits at 1270 nm and receives at 1330 nm. Patch cords must use PC or UPC connectors. Not every Cisco platform supports every module, so check the Cisco 10 Gigabit Ethernet Transceiver Modules Compatibility Matrix for supported devices and software releases.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Single-fibre bidirectional operation over standard single-mode fibre using WDM, which halves fibre usage compared with dual-fibre optics
- Must be paired with an SFP-10G-BXU-I at the far end of the link
- Digital Optical Monitoring per SFF-8472 for real-time optical power, temperature, laser bias current and supply voltage
- Industrial operating temperature range for harsh environments
- Version -02 supports CPRI rates for mobile fronthaul
- Powered from the host SFP+ port, so no external supply is needed

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

Also Known As

FAQs

Technical Specifications

- Standard: 10GBASE-BX10-D (downstream) SFP+ BiDi
- Transmit wavelength: 1330 nm nominal (1320 to 1340 nm)
- Receive wavelength: 1270 nm (1260 to 1280 nm)
- Fibre type: Single-mode (G.652), single strand
- Reach: 10 km (links up to 15 km supported as engineered links with channel insertion loss below 6.2 dB)
- Transmit power: -8.2 to 0.5 dBm
- Receive power: -14.4 to 0.5 dBm
- Maximum power consumption: 1 W
- Temperature class: Industrial
- Operating temperature: -40 to 85 C (-40 to 185 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)
- Dimensions (H x W x D): 8.5 x 13.4 x 56.5 mm
- Weight: 75 g or less
- Bail latch colour: Blue
- Digital optical monitoring: Supported (SFF-8472 MSA)
- CPRI rates: Supported on Version -02
- Pair module: SFP-10G-BXU-I (1270 nm TX / 1330 nm RX)

Also Known As

SFP-10G-BXD-I-RF, SFP-10G-BXD-I=

FAQs

Q: What do I need at the other end of the link?
A: This module must be paired with an SFP-10G-BXU-I at the opposite end. It transmits at 1330 nm and receives at 1270 nm, while the BXU-I transmits at 1270 nm and receives at 1330 nm.

Q: Does it need a licence or subscription?
A: No. It requires no licence or subscription and is powered from the host SFP+ port, drawing a maximum of 1 W.

Q: What fibre and connectors does it use?
A: It runs over a single strand of standard G.652 single-mode fibre. Patch cords must use PC or UPC connectors.

Q: How do I confirm my switch or router supports it?
A: Not all Cisco devices support every module. Check the Cisco 10 Gigabit Ethernet Transceiver Modules Compatibility Matrix for supported platforms and software releases.

Q: How is this different from the SFP-10G-BXU-I?
A: This is the downstream (BX10-D) end, transmitting at 1330 nm and receiving at 1270 nm. The BXU-I is the upstream end with the wavelengths reversed, and the two are used together as a pair.
