Cisco SFP-10/25G-LR-I | 10/25G SFP28 Transceiver, LR, 10km, Industrial Temp

SKU:SFP-10/25G-LR-I

Request Quote
Sale Sold out
Shipping calculated at checkout.

Stock Status: Enquire

20-min response

Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.

Description

This Cisco dual-rate SFP28 long-reach transceiver is built for single-mode fibre links that need to run at either 10G or 25G. It suits Carrier Ethernet, enterprise and mobile fronthaul applications, including CPRI and eCPRI deployments, where links pass through harsher environments such as outdoor cabinets.

The module operates at 10G and 25G on a 1310 nm wavelength and reaches 10 km over single-mode fibre. Engineered links up to 15 km are supported when channel insertion loss is below 9.3 dB. The receiver electrical interface is limiting, and the industrial temperature rating allows deployment where commercial-grade optics would not be suitable.

For supported host platforms and software versions, check the Cisco Transceiver Module Group (TMG) Compatibility Matrix before deployment.

Enquire with XS Network Tech for new or used pricing and availability.

Features

- Dual-rate operation at 10G and 25G
- Industrial temperature range for harsh or outdoor-cabinet environments
- Supports Ethernet, CPRI and eCPRI for mobile fronthaul
- Engineered links up to 15 km when channel insertion loss is below 9.3 dB
- Long-reach 1310 nm optics for single-mode fibre

Warranty

All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.

All technical data should be verified on the manufacturer data sheets.

View full details

specs-tabs

Collapsible content

Technical Specifications

FAQs

Technical Specifications

- Data rate: 10G and 25G (dual rate)
- Form factor: SFP28
- Fibre type: Single-mode fibre (SMF)
- Wavelength: 1310 nm
- Reach: 10 km (up to 15 km as an engineered link if channel insertion loss is below 9.3 dB)
- Protocols: Ethernet, CPRI and eCPRI
- Receiver electrical interface: Limiting
- Temperature range: Industrial (iTemp)

FAQs

Q: Does it run at both 10G and 25G?
A: Yes. It is a dual-rate SFP28 module that operates at 10G and 25G, so the speed follows the host port and the link partner.

Q: What fibre type does it use?
A: It is designed for single-mode fibre at 1310 nm, with a standard reach of 10 km.

Q: Can it reach further than 10 km?
A: Engineered links up to 15 km are supported when the channel insertion loss is below 9.3 dB.

Q: Which protocols does it support?
A: It supports Ethernet, CPRI and eCPRI, which makes it suitable for mobile fronthaul as well as Carrier Ethernet and enterprise links.

Q: How do I confirm host platform support?
A: Check the Cisco Transceiver Module Group (TMG) Compatibility Matrix at https://tmgmatrix.cisco.com/home for supported platforms and software versions.
