Cisco QSFP-H40G-CU4M | 40GBASE-CR4 QSFP+ DAC Cable, 4m, Passive, Orange
SKU:QSFP-H40G-CU4M
Stock Status: Enquire
Need a quote or bulk pricing? Answered within 20 minutes, Sydney business hours.
Description
Description
This Cisco 40GBASE-CR4 direct-attach copper cable links two 40 Gigabit Ethernet QSFP+ ports over 4 metres. It is a passive twinax assembly with a QSFP+ connector on each end and an orange pull tab, built for short-reach connections between Cisco switches and routers. Typical uses include top-of-rack to aggregation links, switch-to-switch runs within a rack or adjacent racks, and high-performance computing and data centre fabrics.
The cable carries 40GBASE-CR4 over 26 AWG copper with a PVC jacket and a 4 m length. Being passive, it has no active electronics and needs no external power supply, which keeps power draw low for short links. It is a hot-swappable QSFP form factor part, with a high-speed electrical interface compliant with IEEE 802.3ba and a QSFP interface that follows SFF-8436 and the QSFP MSA. The operating temperature range is 0 to 70 C.
It is supported on Cisco switches and routers with 40G QSFP ports. Confirm the exact platform and software release against the Cisco Optics-to-Device Compatibility Matrix before deployment.
Enquire with XS Network Tech for new or used pricing and availability.
Features
Features
- Hot-swappable device that plugs into a 40 Gigabit Ethernet Cisco QSFP port
- Passive copper construction with no active electronics, suited to low-power short-reach links
- High-speed electrical interface compliant with IEEE 802.3ba
- QSFP form factor with 2-wire I2C interface and low-speed electrical interfaces compliant with SFF-8436 and the QSFP MSA
- Interoperable with other IEEE-compliant 40GBASE interfaces where applicable
- Tested on Cisco QSFP 40G ports for performance, quality and reliability
Warranty
Warranty
All products sold by XS Network Tech include a 12-month warranty on both new and used items. Our in-house technical team thoroughly tests used hardware prior to sale to ensure enterprise-grade reliability.
All technical data should be verified on the manufacturer data sheets.
View full details
What is the difference between add to cart and request a quote?
Add to Cart lets you purchase in-stock products immediately at listed pricing.
Request a Quote is for customised pricing, volume-based deals, or orders that need a tailored response.
specs-tabs
Collapsible content
Technical Specifications
FAQs
Technical Specifications
- Type: 40GBASE-CR4 QSFP+ to QSFP+ direct-attach copper cable
- Construction: Passive twinax copper assembly
- Cable length: 4 m
- Connector type: QSFP+ on both ends
- Wavelength: N/A (copper)
- Cable gauge: 26 AWG
- QSFP end cable diameter: 9 mm
- Jacket material: PVC
- Jacket colour: Black
- Pull tab colour: Orange
- QSFP connector module max dimensions (H x W x D): 13.5 x 18.4 x 72.4 mm
- QSFP connector module weight: 100 g or less
- Operating temperature: 0 to 70 C (32 to 158 F)
- Storage temperature: -40 to 85 C (-40 to 185 F)
- Standards: IEEE 802.3ba, QSFP+ MSA SFF-8436, SFP+ MSA SFF-8431 and SFF-8461, RoHS 6
- Safety: Cable jacket UL E116441 compliant, ELV compliant
FAQs
Q: Does this cable need a licence or external power?
A: No. It is a passive copper cable with no active electronics, so it needs no external power supply and no licence.
Q: What can this cable connect?
A: It connects two 40G QSFP ports, for example switch-to-switch or top-of-rack to aggregation links, over a maximum length of 4 m.
Q: Which Cisco platforms support it?
A: It is supported on Cisco switches and routers with 40G QSFP ports. Check the exact platform and software release against the Cisco Optics-to-Device Compatibility Matrix.
Q: How does it differ from other QSFP-H40G-CU lengths?
A: This SKU is the 4 m passive version with an orange pull tab. Other lengths in the same passive copper family differ mainly in cable length.
Q: Is it suitable for longer runs between racks?
A: Passive copper is intended for short reach. At 4 m it suits links within a rack or between adjacent racks, while longer runs call for an optical solution.
